Nacra 500 MK2 - Bowsprit Divisible Snuffer

89.
12.1. Bowsprit divisible snuffer
1. Slide the bowsprit over the bowsprit pin on the front
crossbar.
2. Install the bowsprit to the bridle connector
3. Push the bowsprit gently down in order to install the
bowsprit bridle line on the bridle pin.
4. Knot the snuerline with a bowline around the pole and
insert it in the slot of the ring.
The line goes in the slot on the front of the snuer
ring!
5. The other end must be tied on the ring at the bridle.
6. Attach the hooks at the end of the snuerbag to the loops
at the bottom of the trampoline.
3mm
snuer ring tension
