6.
Trim sheet
Jib
Sea
state
wind strength
Mast
rake*
Diamond
tension
forstay
tension
position on
3 to 8 knots 5,2° 170kg 100kg inboard
8 to 12 knots 5,2° 190kg 100kg inboard
12 to 18 knots 5,6° 220kg 100kg middle
18 to 25 knots 5,6° 250kg 100kg outboard
3 to 8 knots 5,2° 170kg 100kg inboard
8 to 12 knots 5,2° 190kg 100kg inboard
12 to 18 knots 5,6° 220kg 100kg middle
18 to 25 knots 5,6° 250kg 100kg outboard
3 to 8 knots 5,2° 170kg 100kg inboard
8 to 12 knots 5,2° 190kg 100kg middle
12 to 18 knots 5,6° 220kg 100kg middle
18 to 25 knots 5,6° 250kg 100kg outboard
mediumlarge
* Mast rake can be measured by measuring the angle difference
between transom and mast. This needs to be done with 100kg
forestay tension and can be done with your phone by using a level
app. Always measure rake with the mast rotatated in the middle
flat
