REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
C001 66-026002-1 Chassis 1 F001 67-026001-0 Fascia 1
C002 66-005004-0 Base Cover 1 F002 67-018001-0 End Cap L 1
C003 75-010004-1 Foot 4 F003 67-018002-0 End Cap R 1
C004 78-001002-0 Foot Pad 4 F004 76-003001-0 LED Lens 6
C005 66-005006-0 BDP Support 1 F005 77-026002-0 Power Button Bezel 1
C006 69-006003-0 Copper Slot 1 F006 77-026001-0 Power Button 1
C007 66-006001-0 Bus Bar 2 F007 75-005001-0 Sleeve 5
C008 70-002004-0 Module Support 2 1 F008 16-27209-00 LED&Ttact Switch Board 1
C009 75-003004-0 Module Lid 1 F009 66-026001-0 Subfascia 1
C010 73-003001-0 Rotate Knob 1
C011 69-002004-0 BDP Pin 4
C012 69-005006-0 BDP Pin 4 R001 67-026003-0 Rear Panel (AH) 1
C013 11-05202-01 Slide Swich 2 67-026002-0 Rear Panel (C) 1
C014 11-05202-00 Slide Swich 2 R002 16-27205-00 Insense Board 1
C015 17-07001-00 Trigger In Socket 1 R003 11-05202-00 Slide Switch 1
C016 17-01002-01 RCA 2 R004 66-010010-0 L Type Bracket 2
C017
01-27201-20/10
Main PCB C/AH 1 R005 17-07102-00 AC Inlet 1
C018 Binding Post 8 R006 16-27207-00 AC Input Board 1
C019 70-005005-0 Heat Sink 2 R007 11-01101-02 Rock Swich 1
C020 70-026004-1 Heat Sink 2b 2
C021 70-026005-1 Heat Sink 1a 1
C022 70-026002-1 Heat Sink 2 2 T001 67-018004-0 Top Cover 1
C023 70-026001-1 Heat Sink 1b 2
C024 70-026003-1 Heat Sink 2a 1
C025 85-005001-0 PC Spacer 8 S001 61-023106-0 Self Taping Screw STB3x6 50
C026 16-27020-00 Amplifier PCB 2 S002 61-023108-0 Self Taping Screw STB3x8 22
C027 16-27040-00 Transistor PCB 2 S003 61-023506-0 Machine Screw MB3x6 24
C028 78-005002-0 Insulation Causion(Small) 8 S004 61-023206-0 Self Taping Screw BTB3x6 4
C029 78-005005-0 Insulation Causion(Big) 16 S005 61-023208-0 Self Taping Screw BTB3x8 26
C030 66-005009-0 Tr. Clamper 16 S006 61-033420-0 Self Taping Screw PTP3x20 8
C031 70-004001-0 Small Heat Sink 2 S007 61-084108-0 Self Taping ScrewSTPW4x
8 6
C032 70-002005-0 Heat Sink 5 S008 61-023508-0 Machine Screw MB3x8 4
C033 69-005001-0 Copper Spacer 3 S009 62-010302-0 Nut GB6170 M3 6
C034 69-006002-0 Copper Spacer 9 S010 61-083515-0 Machine Screw MPW3x15 2
C035 16-27030-00 Standby PCB 1 S011 61-223514-0 Hex Screw M3x14 16
C036 16-27080-00 Module Board 1 S012 64-110070-0 Bolt GB5781 M10x70 1
C037 67-005010-0 Box 1 S013 63-021030-0 Spring Washer GB93 10 2
C038 18-37371-22 Main Transformer(C version) 1 S014 63-011020-1 Washer GB95 10 3
18-37371-12 Main Transformer(AH version
) 1 S015 62-011002-0 Nut GB6170 M10 2
C039 66-005007-0 Metal Disc 1
C040 94-005004-0 Transformer Label 1
C041 66-005008-0 Clamp 2 2
EXPLODED VIEW PARTS LIST
