ELECTRICAL PARTS LIST
REF. NO. P/N
Power AMP Board L Channel (Assembled AMP PCB 01-27220-01 with heatsink)
AMP Raw PCB 16-27220-01 CEM-1
TRANSISTORS
Q305, Q309, Q326, Q316 31-01015-00 2SA1015GR TO-92 Transistors
Q301, Q306, Q307, Q330 31-00872-00 2SA872A TO-92 Transistors
Q302, Q303, Q304, Q329 31-01775-00 2SC1775A TO-92 Transistors
Q308, Q312, Q325 31-01815-00 2SC1815GR TO-92 Transistors
Q318 31-01837-00 2SA1837 TO-220 Transistors
Q310, Q313 31-01220-00 KSA1220A TO-126 Transistors
Q311, Q314 31-02690-00 KSC2690A TO-126 Transistors
Q315 31-02690-00 KSC2690A TO-126 Transistors
Q317 31-04793-00 2SC4793 TO-220 Transistors
Q319, Q321, Q323, Q327 31-01943-00 2SA1943O TO-3P Transistors
Q320, Q322, Q324, Q328 31-05200-00 2SC5200O TO-3P Transistors
DIODES
D301, D302 33-11800-00 18V/0.5W Zener Diodes
D303, D304, D309 33-44148-02 1N4148 SW Diodes
D305, D306 33-44148-03 1N4148 SW Diodes
D307, D308 33-40021-00 1SS88(or BAV21 [BV>200V]) SW Diode
ICS
IC301, IC302 03-00431-00 TL431 TO-92 Regulator
CAPACTORS
C305, C307 05-22052-00 22pF 500V ±20% Ceramic Disk
C308 05-10151-01 100pF 50V ±20% Ceramic Disk
C302 05-22151-01 220pF 50V ±20% Ceramic Disk
C313, C314 05-47152-00 470pF 500V ±20% Ceramic Disk
C320 25-22312-01 22nF 100V ±10% Metallized Polyster Film
C309, C310, C315, C316,
C317, C318, C323
25-10412-02 0.1uF 100V ±10% Metallized Polyster Film
C306 06-22260-00 2200uF 6.3V ±20% Electrolytic
C301, C303, C304 06-10021-01 10uF 25V ±20% Electrolytic
C312, C311 06-10121-00 100uF 25V ±20% Electrolytic
C321 06-10051-00 10uF 50V ±20% Electrolytic
C319, C322 06-10012-00 10uF 100V ±20% Electrolytic
RESISTOR
R367 07-70471-08 t=80° C Posistor
R366 07-70471-09 t=90° C Posistor
R331, R339 07-50479-00 4.7ohms 1/4W ±5% Fusible
R350, R351, R352, R353,
R354, R355, R368, R369
07-50208-01 0.2ohms 1W ±5% Fusible
R359 07-50100-01 10ohms 1W ±5% Fusible
R337, R329 07-50101-02 100ohms 1W ±5% Fusible
R325 07-10101-00 100ohms 1/6W ±5% Carbon Film
R371 07-10222-00 2.2kohms 1/6W ±5% Carbon Film
R313 07-10393-00 39kohms 1/6W ±5% Carbon Film
R324 07-10104-00 100kohms 1/6W ±5% Carbon Film
R308, R320, R336, R340 07-10330-10 33ohms 1/4W ±5% Carbon Film
R304, R306, R312, R314 07-10101-10 100ohms 1/4W ±5% Carbon Film
R370 07-10101-10 100ohms 1/4W ±5% Carbon Film
R347 07-10221-10 220ohms 1/4W ±5% Carbon Film
R346 07-10821-10 820ohms 1/4W ±5% Carbon Film
R311, R315, R361 07-10102-10 1kohms 1/4W ±5% Carbon Film
R345 07-10122-10 1.2kohms 1/4W ±5% Carbon Film
R364 07-10682-10 6.8kohms 1/4W ±5% Carbon Film
R310, R316, R333, R342,
R343, R335
07-10103-10 10kohms 1/4W ±5% Carbon Film
R362 07-10153-10 15kohms 1/4W ±5% Carbon Film
R302, R363, R365 07-10223-10 22kohms 1/4W ±5% Carbon Film
R305, R327 07-10393-10 39kohms 1/4W ±5% Carbon Film
R326 07-10104-10 100kohms 1/4W ±5% Carbon Film
R303 07-20101-00 100ohms 1/6W ±5% Metal Film
R301 07-20471-00 470ohms 1/6W ±5% Metal Film
R307 07-29100-00 910ohms 1/6W ±1% Metal Film
DESCRIPTION
