ELECTRICAL PARTS LIST
REF. NO. P/N
DESCRIPTION
R328 07-20101-10 100ohms 1/4W ±5% Metal Film
R309, R323 07-21000-10 100ohms 1/4W ±1% Metal Film
R321 07-21001-10 1kohms 1/4W ±1% Metal Film
R358 07-20101-21 100ohms 0.5W ±5% Metal Film
R317 07-21500-10 150ohms 1/4W ±1% Metal Film
R318 07-24702-10 47kohms 1/4W ±1% Metal Film
R322 07-29101-21 9.1kohms 0.5W ±1% Metal Film
R319 07-21002-20 10kohms 0.5W ±1% Metal Film
R330, R338 07-30339-01 3.3ohms 1W ±5% Metal Oxdized Film
R348, R349 07-30750-01 75ohms 1W ±5% Metal Oxdized Film
R332, R341 07-30511-01 510ohms 1W ±5% Metal Oxdized Film
R360 07-30339-04 3.3ohms 1W ±5% Metal Oxdized Film
R334, R344 07-30222-03 2.2kohms 3W ±5% Metal Oxdized Film
R356, R357 07-40507-05 0.05ohms 5W ±10% Ceramic
INDUCTORS
L303 08-01010-00 1uH 10% Inductor
L301, L302 08-02100-00 10uH 10% Inductor
POT
VR301 09-02181-00 180ohms Semi-POT
VR302 09-02501-00 500ohms Semi-POT
Power AMP Board R Channel (Assembled AMP PCB 01-27220-02 with heatsink)
TRANSISTORS
Q405, Q409, Q416, Q426 31-01015-00 2SA1015GR TO-92 Transistor
Q401, Q406, Q407, Q430 31-00872-00 2SA872A TO-92 Transistor
Q402, Q403, Q404, Q429 31-01775-00 2SC1775A TO-92 Transistor
Q418 31-01837-00 2SA1837 TO-220 Transistor
Q431 31-02878-00 2SC2878A TO-92 Transistor
Q408, Q412, Q425 31-01815-00 2SC1815GR TO-92 Transistor
Q410, Q413 31-01220-00 KSA1220A TO-126 Transistor
Q411, Q414 31-02690-00 KSC2690A TO-126 Transistor
Q415 31-02690-00 KSC2690A TO-126 Transistor
Q417 31-04793-00 2SC4793 TO-220 Transistor
Q419, Q421, Q423, Q427 31-01943-00 2SA1943O TO-3P Transistor
Q420, Q422, Q424, Q428 31-05200-00 2SC5200O TO-3P Transistor
DIODES
D401, D402 33-11800-00 18V 0.5W Zener Diode
D403, D404, D409 33-44148-02 1N4148 Switch Diode
D405, D406 33-44148-03 1N4148 Switch Diode
D407, D408 33-40021-00 1SS88(or BAV21 [BV>200V]) Switch Diode
ICS
IC401, IC402 03-00431-00 TL431 TO-92 Regulator
CAPACTORS
C408 05-10151-01 100pF 50V ±20% Ceramic Disk
C405, C407 05-22052-00 22pF 500V ±20% Ceramic Disk
C402 05-22151-01 220pF 50V ±20% Ceramic Disk
C413, C414 05-47152-00 470pF 500V ±20% Ceramic Disk
C420 25-22312-01 22nF 100V ±10% Metallized Polyster Film
C421 06-10051-00 10uF 50V ±20% ELECT
C409, C410, C415, C416,
C417, C418, C423
25-10412-02 0.1uF 100V ±10% Metallized Polyster Film
C411 06-10121-00 100uF 25V ±20% Electrolytic
C412 06-10121-00 100uF 25V ±20% Electrolytic
C401, C403, C404 06-10021-01 10uF 25V ±20% Electrolytic
C406 06-22260-00 2200uF 6.3V ±20% Electrolytic
C419, C422 06-10012-00 10uF 100V ±20% Electrolytic
RESISTOR
R467 07-70471-08 t=80° C Posistor
R466 07-70471-09 t=90° C Posistor
R431, R439 07-50479-00 4.7ohms 1/4W ±5% Fusible
R450, R451, R452, R453,
R454, R455, R468, R469
07-50208-01 0.2ohms 1W ±5% Fusible
R459 07-50100-01 10ohms 1W ±5% Fusible
R437, R429 07-50101-02 100ohms 1W ±5% Fusible
R425 07-10101-00 100ohms 1/6W ±5% Carbon Film
