ELECTRICAL PARTS LIST
REF. NO. P/N
DESCRIPTION
R471 07-10222-00 2.2kohms 1/6W ±5% Carbon Film
R413 07-10393-00 39kohms 1/6W ±5% Carbon Film
R424 07-10104-00 100kohms 1/6W ±5% Carbon Film
R408, R420, R436, R440 07-10330-10 33ohms 1/4W ±5% Carbon Film
R404, R406, R412, R414,
R470
07-10101-10 100ohms 1/4W ±5% Carbon Film
R447 07-10221-10 220ohms 1/4W ±5% Carbon Film
R446 07-10821-10 820ohms 1/4W ±5% Carbon Film
R445 07-10122-10 1.2kohms 1/4W ±5% Carbon Film
R411, R415, R461 07-10102-10 1kohms 1/4W ±5% Carbon Film
R464 07-10682-10 6.8kohms 1/4W ±5% Carbon Film
R410, R416, R433, R442,
R443, R435
07-10103-10 10kohms 1/4W ±5% Carbon Film
R462 07-10153-10 15kohms 1/4W ±5% Carbon Film
R402, R463, R465 07-10223-10 22kohms 1/4W ±5% Carbon Film
R405, R427 07-10393-10 39kohms 1/4W ±5% Carbon Film
R426 07-10104-10 100kohms 1/4W ±5% Carbon Film
R403 07-20101-00 100ohms 1/6W ±5% Metal Film
R401 07-20471-00 470ohms 1/6W ±5% Metal Film
R407 07-29100-00 910ohms 1/6W ±1% Metal Film
R428 07-20101-10 100ohms 1/4W ±5% Metal Film
R409, R423 07-21000-10 100ohms 1/4W ±1% Metal Film
R417 07-21500-10 150ohms 1/4W ±1% Metal Film
R421 07-21001-10 1kohms 1/4W ±1% Metal Film
R418 07-24702-10 47kohms 1/4W ±1% Metal Film
R458, R472 07-28201-20 8.2kohms 0.5W ±1% Metal Film
R422 07-29101-21 9.1kohms 0.5W ±1% Metal Film
R419 07-21002-20 10kohms 0.5W ±1% Metal Film
R430, R438, R460 07-30339-01 3.3ohms 1W ±5% Metal Oxdiode Film
R448, R449 07-30750-01 75ohms 1W ±5% Metal Oxdiode Film
R432, R441 07-30511-01 510ohms 1W ±5% Metal Oxdiode Film
R434, R444 07-30222-03 2.2kohms 3W ±5% Metal Oxdiode Film
R456, R457 07-40507-05 0.05ohms 5W ±10% Ceramic
INDUCTORS
L403 08-01010-00 1uH 10% Inductor
L401, L402 08-02100-00 10uH 10% Inductor
POT
VR401 09-02181-00 180ohms Semi-POT
VR402 09-02501-00 500ohms Semi-POT
Power Board
Power Raw PCB 16-27210-01
Assembled Power PCB 01-27201-20/10 C272 Main Power PCB C-version / AH-version
TRANSISTORS
Q702, Q704, Q706, Q707,
Q715
31-01015-00 2SA1015GR TO-92 Transistors
Q712 31-00872-00 2SA872A TO-92 Transistors
Q710, Q711 31-01775-00 2SC1775A TO-92 Transistors
Q701, Q703, Q705, Q713,
Q714, Q716, Q717, Q718
31-01815-00 2SC1815GR TO-92 Transistors
Q709 31-01220-00 KSA1220A TO-126 Transistors
Q708 31-02690-00 KSC2690A TO-126 Transistors
DIODES
D703, D704, D705, D706,
D710, D712, D713, D719,
D720, D721, D722
33-44148-02 1N4148 Switch Diode
D707, D708, D709, D711,
D723, D724
33-44148-03 1N4148 Switch Diode
D716 33-44148-04 1N4148 Switch Diode
D702 33-25401-00 1N5401 Switch Diode
D718 33-11000-00 10V 0.5W Zener Diode
D714, D715 33-12400-00 24V 0.5W Zener Diode
B701, B702 33-31042-00 KBU1004 Rectifier Bridge
B703, B704 33-30142-00 DB104 Rectifier Bridge
