NAD C 356BEE - Electrical Parts List - Links and Metal Parts; Main Board Links and Connectors; Heatsinks and Metal Parts

PHONE1 J17-02002-00 PHONEJACK2
BINDING POSTS
Binding Post Assy˄Long˅
02-03560-01 Hansong assembled
SPEAKER TERMINAL J17-03002-17 CL159706N
Binding Post 77-185002-0 16-001-0439-93
BDP Pin(Long) 69-185002-0 HS4-C356-B12V1-M007
Spring Washer 63-020511-2 SPR5.4*8.5*1.1
Binding Post Assy˄Short˅
02-03560-02 Hansong assembled
SPEAKER TERMINAL J17-03002-17 CL159706N
Binding Post 77-185002-0 16-001-0439-93
BDP Pin(Short) 69-185001-0 HS4-C355-B12V1-M006
Spring Washer 63-020511-2 SPR5.4*8.5*1.1
LINKS
J1, J25, J28, J29, J34, J35,
J36, J38, J39, J41, J42, J43,
J46, J53, J58, J59, J63, J66,
J72, J75, J84, J88, J97, J99,
J102, J104, J106, J112, J113,
J120, J122, J127, 129, J132,
J138, J139, J150, J151, J152,
J154, J165, J166, J172, J183,
J185, J186, J187, J190, J204,
J205
21-06500-00 L=5mm
J26, J40, J44, J45, J48, J50,
J51, J52, J56, J57, J71, J73,
J79, J81, J82, J87, J96, J98,
J105, J115, J117, J125, J126,
J128, J131, J135, J136, J141,
J143, J145, J147, J149, J159,
J163, J164, J175, J177, J178,
J181, J193, J194, J199
21-06750-00 L=7.5mm
J3, J62, J77, J80, J86, J100,
J103, J116, J118, J119, J121,
J130, J153, J170, J179, J191,
J195, J196, J203
21-06101-00 L=10mm
J11, J12, J27, J37, J61, J65,
J89, J92, J101, J140, J142,
J144, J146, J156, J157, J171,
J174, J176, J180, J189, J192,
J197, J198
21-06121-01 L=12.5mm
J4, J7, J47, J49, J54, J55,
J60, J64, J76, J78, J108,
J111, J134, J137, J160, J162,
J168, J173, J182, J200, J201,
J206, J209
21-06151-00 L=15mm
J13, J67, J68, J94, J95, J123,
J158
21-06181-00 L=18mm
J5, J30, J31, J32, J33, J83,
J85, J107, J124, J133, J155,
J169, J202, J210
21-06201-00 L=20mm
J110 21-06221-01 L=22.5
J15, J17, J18, J19, J20, J21,
J22, J23, J24, J69, J70, J74,
J90, J109, J184
21-06251-00 L=25
J2 21-10750-00 L=7.5
J10,J114 21-10121-01 L=12.5mm
J91 21-10151-00 L=15
J93, J167, J207, J208, J213 21-10201-00 L=20
J6, J148 21-10251-00 L=25
J8 21-10301-00 L=30
ASSY HEATSINK
8VHGRQ.6&
61-023208-0 Screws,BTB3×8,black
Used on R467,R439 61-023208-0 Screws,BTB3×8,black
Used on CLAMPER 61-224516-1
Hexagon Socket Head
Screw,GB/T70.1, M4×16
Used on CLAMPER 63-010408-0
Plain Washer,GB97.1-85 φ
4
Used on CLAMPER 63-020411-0 Spring Washer,GB93-87 φ4
CLAMPER 66-001009-0 HS4-C320-B009V1-M012
SECC 81-001004-0 SECC-N4 1219×530×1.6
Main Heatsink 70-091004-1
6063 T5,HS4-C355-
B009V1-M004 B
Heat Conductive Pad 78-001004-0 Sil-Pad K06-122
R467 07-70471-08 PTH9M04BF471TS2F333
R439 07-70471-09 PTFM04BE471Q2N34BO
Q119, Q219 31-02690-00 KSC2690AYSTU
Q114, Q214 J31-02121-00 2SA2121-O
Q115, Q215 J31-05949-00 2SC5949-O
GND-BAR 69-019001-0 Busbar
GND-2 69-019003-0 Busbar
METAL PARTS
