H1 70-091005-0 Heatsink,ALU 6063 BLACK
H2, H3 70-185002-0
HS4-C356BEE-B12V1-
M009
H4 H5 70-019003-1
+HDWVLQN+6&%9
0'
H6,H7 70-002005-0 Heatsink,15×35mm F35
Used on Heatsink 4 61-023204-0 Self Taping Screws,BTB3X4
Used on Heatsink2,3 61-022510-5 Screws,IB-25100-1HE
Used on Heatsink1 61-022514-5 Screws,IB-25140-1HE
Used on
Heatsink2,KSC2690,A1220(6)
61-022208-6 Screws,BTB2.6×8
Used on
Heatsink2,2SA1930&2SC517
1(4)
61-023106-0 Screws,STB3×6
Used on +HDWVLQN1,2,3
62-010202-5 Nuts,M2.5
P1-L,P2-L,P3-R,P4-R 61-382003-5 RIVET,GB975-86-2.5×3
P5-GND 61-382003-5 RIVET,GB975-86-4x3.2
Cable Tie 84-001003-0 YJ-100
CIRCUIT NO. PART NO. DESCRIPTION
DIODES
D23, D24, D25, D26 33-44148-17 LL4148
TRANSISTORS
Q26 31-01015-03 A1015
Q27 31-01815-03 C1815
Q22, Q25, Q202, Q204 J31-01312-00 2SA1312-GR
Q23, Q24, Q201, Q203 J31-03324-00 2SC3324-GR
Q28 31-01661-00 KTA1661-Y
Q29 31-04373-00 KTC4373-Y
CAPACITORS
C28, C29 26-39051-00 39pF, 50V, 5%, NPO
C22, C224 26-10251-10 1nF, 50V, 5%, NPO
C23, C24 06-10031-02 VSS, 10uF, 35V, ±20%
C203, C204 06-22011-05 VSS, 22uF, 16V, ±20%
RESISTORS
R254, R255 07-90100-00 10Ω, ±5%
R215, R216, R272, R273 07-91509-00 15Ω, ±1%
R249 07-96809-00 68Ω, ±1%
R203, R206, R219, R220 07-98209-00 82Ω, ±1%
R211, R212, R259 07-91000-00 100Ω, ±1%
R269 07-93300-00 330Ω, ±1%
R201, R205 07-93902-00 39KΩ, ±1%
R223 07-94702-00 47KΩ, ±1%
R29, R210 07-95602-00 56KΩ, ±1%
R221, R222 07-91003-00 100KΩ, ±1%
R202, R204 07-92203-00 220KΩ, ±1%
INDUCTORS
L22 08-04101-00 100uH
CONNECTORS
CZ21(INSERTED TO CB21
ON THE MAIN BOARD)
13-12508-11 S006
CIRCUIT NO. PART NO. DESCRIPTION
DIODES
D13, D14, D15, D16 33-44148-17 LL4148
TRSISTORS
Q16 31-01015-03 A1015
Q17 31-01815-03 C1815
Q12, Q15, Q102, Q104 J31-01312-00 2SA1312-GR
Q13, Q14, Q101, Q103 J31-03324-00 2SC3324-GR
Q18 31-01661-00 KTA1661-Y
Q19 31-04373-00 KTC4373-Y
CAPACITORS
C18, C19 26-39051-00 39pF, 50V, ±5%,NPO
C12, C124 26-10251-10 1nF, 50V, ±5%,NPO
C13, C14 06-10031-02 VSS, 10uF, 35V, ±20%
C103, C104 06-22011-05 VSS, 22uF, 16V, ±20%
RESISTORS
R154, R155 07-90100-00 10Ω, ±5%
R115, R116, R172, R173, 07-91509-00 15Ω, ±1%
R149 07-96809-00 68Ω, ±1%
R103, R106, R119, R120 07-98209-00 82Ω, ±1%
R111, R112, R159 07-91000-00 100Ω, ±1%
R169 07-93300-00 330Ω, ±1%
R101, R105 07-93902-00 39KΩ, ±1%
R123 07-94702-00 47KΩ, ±1%
R19, R110 07-95602-00 56K
Ω, ±1%
R121, R122 07-91003-00 100KΩ, ±1%
R102, R104 07-92203-00 220KΩ, ±1%
INDUCTORS
L12 08-04101-00 100uH
PCB-8: AMP SMD module board
LEFT PART # 01-35602-00
PCB-7: AMP SMD module board RIGHT PART # 01-35608-00
30
