NAD C 356BEE - Preamp Module Board Parts List (PCB-9); Preamp Module Transistors; Preamp Module Capacitors; Preamp Module Resistors

CONNECTORS
CZ11(INSERTED TO CB11
ON THE MAIN BOARD)
13-12508-11 S006
CIRCUIT NO. PART NO. DESCRIPTION
TRSISTORS
Q61, Q62 J31-00209-00 2SK209-GR
Q63, Q65 J31-01312-00 2SA1312-GR
Q69, Q610, Q611, Q612 J31-03324-00 2SC3324GR
Q64, Q66 31-01201-01 2SA1201-Y
Q67, Q68 J31-02881-01 2SC2881-Y
CAPACITORS
C63, C64, 26-22051-00 22pF, 50V, ±5%,NPO
C69, C610 26-10151-00 100p, 50V, ±5%,NPO
C61, C62 26-22151-00 220p, 50V, ±5%,NPO
C613, C612 26-10251-00 1nF, 50V, ±5%,X7R
C65, C66, C67, C68 26-10451-00 0.1uF, 50V, ±10%,Y5V
RESISTORS
R615, R616, R617, R618,
R619, R620
07-90100-00 10Ω, ±5%
R61, R62 07-90221-00 220Ω, ±5%
R69, R610 07-94300-00 430Ω, 1%
R624, R625 07-90621-00 620Ω, ±5%
R67, R68, R611, R612, R622
R623
07-90102-00 1KΩ, ±5%
R613, R614 07-90103-00 10KΩ, ±5%
R63, R64 07-90225-00 2.2MΩ, ±5%
CONNECTORS
CZ61(INSERTED TO
CB32.CB33 ON THE MAIN
BOARD)
13-12509-01 S006
CIRCUIT NO. PART NO. DESCRIPTION
DIODES
D319 33-44148-00 1N4148
D321 33-25819-00 1N5819
TRANSISTORS
Q401, Q403 31-01015-00 2SA1015 GR
Q402, Q404 31-01815-00 2SC1815
CAPACITORS
C302, C303 05-22113-01 220p, 1KV, ±10%
C327, C328 25-22361-01 22n, 63V, ±5%
C322, C321,C337, C338 25-10461-07 0.1uF, 63V, ±5%
C329, C330 25-10461-05 0.1uF, 63V, ±5%
C331, C332 25-22461-02 0.22uF, 63V, ±5%
C333, C334 25-10561-02 1u, 63V ±5%
C339, C340 06-10951-08 1uF, 50V, ±20%
C417 C418 06-47951-00 4.7uF, 50V, ±20%
C301 06-10051-00 10uF, 50V, ±20%
C325 C326 06-47021-06 47uF, 25V, ±20%
RESISTORS
R403 R405 R406 R407 07-10102-50 1K, 1/6W, ±5%
R402 R404 07-10103-50 10K, 1/6W, ±5%
R387 R388 07-10203-50 20K, 1/6W, ±5%
R364 07-10513-50 51K, 1/6W, ±5%
R363 07-10513-51 RT14, 51K, 1/4W, ±5%
R327 R328 07-21800-50 180R, 1/6W, ±1%
R325 R326 07-23900-51 390R, 1/4W, ±1%
R331 R332 07-23900-50 390R, 1/6W, ±1%
R324 07-27500-50 750R, 1/6W, ±1%
R323 07-27500-51 750R, 1/4W, ±1%
R329 R330 07-21501-50 1K5, 1/6W, ±1%
R322 07-23301-50 3K3, 1/6W, ±1%
R321 07-23301-51 3K3, 1/4W, ±1%
POTS
VR303 VR304 09-02103-00 10K
RT31 RT32 J09-01103-14 10KA
RT33 J09-01203-05 20KB
RT34 J09-01203-06 20K MN
LINKS
J302 J304 J308 J309 J313
J314 J321
21-06500-00 L=5
J301 J303 J310 21-06750-00 L=7.5
J312 J320 21-06101-00 L=10
J307 J315 J316 J322 21-06121-01 L=12.5
J306 21-06201-00 L=20
J317 21-06221-01 L=22.5
J305 J318 21-06251-00 L=25
RELAYS
RL311 12-02202-03 JRC-27F/005/S
CONNECTORS
CZ37 13-22513-01
FPC1.25 13PINˈ
Pitch=1.25mm
METAL PARTS
PCB-9: Preamp module board NSP, Part number 01-35504-00 both Line In and Line Out
PCB-4: Tone and Volume board 01-35603-00
