NAD C 356BEE - Keyboard Parts List (PCB-3); Keyboard Integrated Circuits (ICs); Keyboard Diodes; Keyboard Transistors

6HOI7DSLQJ6FUHZ
61-023106-0 STB3×6
CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC73 03-00162-01
STC12C5A16S2-35I-
LQFP44
IC76 03-00232-01
MAX232D+/MAX232ID+/MA
X232CSE+/MAX232ESE+
IC72 03-00038-40 HS0038B4
DIODES
D710 D711 D712 D713 D714
D723 D724
33-44148-17 1N4148W-NR
D722 33-05819-01 1N5819HW-7-F, 40V, 1A
D71 D72 D73 D74 D75 D76
D77 D78 D708 D709 D716
33-50360-30 φ3, BLUE, BUL33842
D717 33-50565-12 Φ5 three color
TRANSISTORS
Q722 Q723 Q724 31-01015-03 A1015
Q71 Q73 Q79 Q710 Q711
Q712 Q713 Q714 Q715
Q718 Q719 Q720 Q721 Q727
31-01815-03 C1815 SOT23
CAPACITORS
C769 C770 N.I.
C79 C710 26-27051-01 27pJ, 50V, 0805, NPO
C758 C759 26-10151-01 100pJ,50V,0805,NPO
C771 C772 26-10251-01 1nK, 50V, 0805, X7R
C71 C714 C715 C716 C717
C718 C719 C720 C721 C724
C766 C767 C768
26-10351-01 10nK, 50V, 0805, X7R
C761 26-10451-10 0.1uK, 50V, 0603, X7R
C711 C760 26-10451-11 0.1uK, 50V, 0805, X7R
C722 C762 C763 C764 C765 26-10551-01 1uF, 50V, Y5V
C78 06-10011-23
CD70H,16V,10uF,±20%,105
ć,F5.0
C723 06-10111-30
CD70H,16V,100uF,±
20%,105ć,F5.0
RESISTORS
R796 R797 N.I.
R708 R765 R767 07-90100-01 10Ω, ±5%,0805
R768 R769 R782 R783 07-90101-01 100Ω, ±5%,0805
R706 R712 07-95600-01 560Ω, ±1%, 0805
R746 R753 07-90102-01 1KΩ, ±5%, 0805
R709 07-91201-01 1.2KΩ, ±1%, 0805
R725 R726 R727 R728 R759
R788 R789 R798
07-92201-01 2.2KΩ, ±1%, 0805
R718 R719 R720 R721 R741
R742 R743 R744 R745 R747
R748 R749 R750 R751 R752
R754 R755 R756 R760 R761
R776 R777 R790 R791
07-90472-01 4.7KΩ, ±5%, 0805
R784 07-90512-01 5.1KΩ, ±5%, 0805
R701 R704 R707 R710 R713
R714 R716 R72 R73 R74
R75 R76 R77 R723 R724
R730 R731 R732 R733 R734
R735 R736 R737 R738 R739
R740 R762 R763 R766 R773
R774 R775 R778 R779 R780
R781 R785 R793 R799
07-90103-01 10KΩ, ±5%, 0805
R770 07-90203-01 20KΩ, ±5%, 0805
CRYSTAL
Y71 04-11102-00 11.0592MHz, CL=15pF
INDUCTORS
L71 21-06500-00 L=5mm
CONNECTORS
PHONE71 J17-02001-02 SCJ340R0GBS0B00
CZ75——CB35 14-35603-01
UL2547#24AWG*2C
white/black/red,JC25-3Y
bend pins ,XHB-3Y
plug,L=650mm
CZ78——CB78 14-35606-00
UL2854#26AWG*5C
white/red/yellow/green/blue
or others,JC25-6Y bend
pins,XHB-6Y plug,L=620mm
CZ71 14-35609-00
UL2468#26AWG*9C,white,J
C20-9Y bend pins,PH-9Y
plug,L=450mm
PCB-3: Keyboard 01-35607-00
