CZ76 14-35615-00
UL2468#26AWG*7C+8C,JC
20-15Y bend pins,PH-15Y
plug,L=470mm
Switch
S71, S72, S73, S74, S75,
S76, S77,S79,S710 S711
S712
11-04101-05 5mm,Tact Switch
METAL PARTS
IR Bracket 66-091004-0 HS4-C355-B009V1-M011
Sleeve 1P 75-062001-0 1P
MP PAD 75-091002-0
HS4-C355BEE-B009V1-
P007
CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC55 03-00317-00 LM317T
IC53 A03-00817-04 PC817X2J000F
IC51 03-00274-00 TNY274PN
DIODES
D52 33-30142-01 DB104S, 1A 400V
D510 33-30162-02 DB105S, 1A 600V
D533 33-44148-00 1N4148
D57 33-14309-00 4.3V, 0.5W, ±2%
D541 33-25819-00
1N5819,䭓ᓩ㒓
D59 33-20540-00 SR540
D58 33-20107-00 FR107
D58 or 33-24006-00 UF4006
D536 33-26200-00 P6KE200A
D513 33-24004-00 1N4004
D56 D537 33-30142-00 DB104
D531 D532 33-60116-00 TIC116D/BT151-500R
D51 D55 33-30822-03 8A/200V
TRANSISTORS
Q501 Q518 Q520 Q522 31-01815-03 C1815 SOT23
Q59 Q510 Q517 Q519 31-01015-03 A1015 SOT23
CAPACITORS
C544 26-10351-00 10nK,50V,0603,X7R
C530 26-10411-00 0.1uF/16V, X7R
C557 26-10412-01 0.1uF/100V, X7R
C536 C550 24-10412-01 0.1u,100V,20%
C51 C52 25-10322-00 10n/250V 10%
C555 06-10011-00 10uF, 16V, ±20%
C531 06-10042-00 CD11H, 10uF/400V, 20%
C551 06-10111-00 100uF, 16V, ±20%
C533 C545 06-33111-01
CD110,330uF,16V,±
20%,F5.0,
C546 A05-22242-00
2.2nF, 400V(X1), 250V(Y1),
±5%
C53 C539 A05-47242-00 4n7p, 400V, ±20%
C54 A25-33422-00 MKP62, 275V, 0.33uF 10%
C523 C524 06-22261-02
RGA222M1JBK-1836,
63V,2200uF,±20%,105ć
C523 C524 or 06-22261-01
CD267,63V,2200uF,±
20%,105ć
C527 C552 06-33221-02
RGA332M1EBK-1625
,25V,3300uF,±20%,105ć
C527 C552 or 06-33221-01
CD263X,25V,3300uF,±
20%,105ć
C517 C518 06-22361-01
22000uF/63V, 20%, two
leaders, 105ć
RESISTORS
R575 R579 R582 07-90102-00 1KΩ, ±5%
R580 07-90472-00 4.7KΩ, ±5%
R581 07-90103-00 10KΩ, ±5%
R567 07-90334-00 330KΩ, ±5%
R533 07-90105-00 1MΩ, ±5%
R561 R565 07-90101-01 100Ω, ±5%
R532 07-92200-01 220Ω, ±1%
R558 R559 R560 R562 07-90102-01 1KΩ, ±5%
R534 07-92201-01 2.2KΩ, ±1%
R566 07-90472-01 4.7KΩ, ±5%
R563 R564 07-90223-01 22KΩ, ±5%
R570 07-10101-50 100Ω, ±5%, 1/6W
R571 07-10102-50 1KΩ, ±5%, 1/6W
R544 07-10223-51 22KΩ, ±5%, 1/4W
R578 07-22550-00 255, 1/6W, ±1%
R577 07-29100-50 910, 1/6W, ±1%
R584 07-30109-20 RY21, 1Ω, 1/2W, ±5%
R531 07-40507-03 0.05/3W 5% CE
FUSES
F51(C verstion) A20-12252-00 T2.5AL250V
F51(AH version) A20-12502-00 T5AL250V
PCB-2: Power board 01-35605-10 AH or 01-35605-20 C
33
