NAD C 356BEE - Smaller Board Parts Lists; Headphone Board Parts (PCB-6); RS232 Board Parts (PCB-5); Main Transformer Details

Fuse Holder for F51 20-20000-00 HF-004
INDUCTORS
L51
A22-00183-00
2x1.8mH,73A173-2XY-9330
L52 08-01100-00 LGB0810-10uH
T51(Standby transformer) A22-00016-06 EE16,Ben-10
RELAYS
RL51 A12-02101-01 DH1U 15A/250V 5V
CONNECTORS
CB52 CB54 CB58 CB510 13-23902-00 VH 3.96A-2A
CB55 CB56 13-23903-01
VH 3.96A-3A(delete the
centerneedle)
CB59 13-23903-01
VH 3.96A-3A(delete the
centerneedle)
CB57 13-23903-01
VH 3.96A-3A(delete the
centerneedle)
CB51 13-23907-00 VH 3.96A-7A
CB53 --- CB47(MAIN
BOARD)
14-35610-00
UL1007#26AWG gray,SCN-
10Y pins,XHB-10Y
plug,L=240mm
METAL PARTS
H503 70-002005-0 15×35mm
H503 61-023204-0 BTB3X4
H501, H502 70-004003-1 Heatsink,L=60mm
Used on H501, H502 61-083515-0
SELF TAPING
SCREW,MPW3×15
Used on H501, H502 62-010302-0 Nut,M3
Used for C53 C539 C546 78-001001-1 Sleeve Boot
CIRCUIT NO. PART NO. DESCRIPTION
RESISTORS
R454, R455 07-30101-04 100Ω, 2W, ±5%
CONNECTORS
JK41 17-02001-41
CK-6.35-02 9P˄with nuts˅
CZ45--CB45 14-35603-00
UL2468#26AWG*3C,JC25-
3Y bend pins ,XHB-3Y
plug,L=40mm
CIRCUIT NO. PART NO. DESCRIPTION
RESISTORS
R792 07-10101-50 100R, 1/6W, ±5%
CONNECTORS
CZ79 13-22504-00 XHB2.5A-4A
CZ78 13-22506-00 XHB2.5A-6A
CZ77 17-08009-00 DB9, 7906-9-F-B(with nuts)
METAL PARTS
BRACKET 66-010010-0 SECC-N4 T=1.00
Used on BRACKET 61-023106-0 Screw,STB3×6
CIRCUIT NO. PART NO. DESCRIPTION
C VERSION A18-35617-20 HA150C-0637
AH VERSION A18-35617-10 HA150C-0638
CONNECTORS
MAIN board (P-GND) --TONE
board (P-GND)
14-35601-01
UL1015#16AWG
black,L=30mm
CB56——Power Switch A14-31502-12
9+$<GHOHWHFHQWHU
QHHGOHSOXJ$:*
8/UHGEOXHPPOHQ
JWK
CB55——AC Inlet 14-35502-00
9+$<GHOHWHFHQWHU
QHHGOHSOXJ$:*8/
UHGPPOHQJWK
CZ37---CB37(Main BOARD to Tone BOARD FFC) 14-06613-01
13Pin,45mm,Pitch=1.25mm,
same sides FFC.
AC INLETS A17-07002-07 SS-7BA-4.0
AC INLETS or A17-07002-00 3516-T1C02
ROCKER SWITCH A11-01101-03
RF-1003-BB2, 10A 250V,
TV-5
AC Outlets(AH) A17-07002-10 JT-0467A
AC CORD˄AH˅
JA15-10125-01
JT-0467ALP-13W &,SVT
18AWG×2,Black 6'& LP-16
AC CORD˄C˅
JA15-10250-20
PE-224 & H05VV-F, 2×
0.75mm2,2C Black 6'& LS-
20
METAL PARTS
REAR PANEL AH 67-185001-0B
HS4-C356Bee-B12V1-SR01
HS4-C356Bee-B12V1-M004
Others
MAIN TRANSFORMER
PCB-6: Headphone board 01-35604-00
PCB-5: RS232 board 01-35609-00
34
