ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
R729, R731 07-22202-10
22K¡
1/4W ±1% Metal Film Resistor
R751 07-22702-10
27K¡
1/4W ±1% Metal Film Resistor
R758 07-26202-00
62K¡
1/6W ±1% Metal Film Resistor
R767 07-23903-10
390K¡
1/4W ±1% Metal Film Resistor
R102, R104, R106, R108,
R110, R112, R114, R116,
R117, R202, R204, R206,
R208, R210, R212, R214,
R216, R218
07-20105-00
1M¡
1/6W ±5% Metal Film Resistor
R20, R21 07-30339-01
3R3¡
1W ±5%
Metallized Oxid Film Resistor
R762, R763 07-30221-05
220¡
2W ±5%
Metallized Oxid Film Resistor
R779 07-30221-04
220¡
3W ±5%
Metallized Oxid Film Resistor
R738, R700 07-30271-02
270¡
2W ±5%
Metallized Oxid Film Resistor
R722, R723 07-50330-01
33¡
1/2W ±5%
Fusible Resistor
R124, R223 07-50750-00
75¡
1/2W ±5%
Fusible Resistor
R746, R747, R748, R749 07-50109-01
1¡
1W ±5%
Fusible Resistor
R710 07-40257-03
0.025¡
3W ±2% Ceramic Case
VR701 09-02503-00
50K¡
Variable Resistor
RV5 09-02102-00 1KA, RV142 POT
INDUCTORS
L1, L2 08-01010-00 1uH Inductor
RELAYS
RLO1, RLO2, RLO3, RLO4 12-03101-04 JQX-115F/036/1HS1 Relay
RLO1, RLO2, RLO3, RLO4 12-03101-03 (or JQX-115F/024/1HS1) Relay
RL2, RL5, RL6, RL7, RL8,
RL9, RL10, RL11, RL12
12-02101-02 JRC-27F/012/S Relay
SWITCHS
SW2 11-05202-00 SSSU122NB1 SLIDE SWITCH
SW3 11-05202-01 SSSU142NB1 SLIDE SWITCH
CONNECTORS
PJ701 17-07001-00 PY301-030-100 Headphone Socket
RCA1, RCA2, RCA3, RCA4 17-01006-00 AV6-8.4-13 RCA Socket
JIR 17-02002-00 SCJ351P00XS0B00 Dual 3.5 Headphone Socket
TP701-TP702 13-12502-00 2PIN Connector
CB702 13-22502-00 XHB 2.5A-2A Connector
CB705 13-22503-00 XHB 2.5A-3A Connector
CB303 13-22505-00 XHB 2.5A-5A Connector
CB403 13-22506-00 XHB 2.5A-6A Connector
CB501 13-22508-00 XHB 2.5A-8A Connector
CB302, CB402 13-22509-00 XHB 2.5A-9A Connector
CB806, CB807 13-22510-00 XHB 2.5A-10A Connector
CB304, CB404 13-23904-00 VH 3.96A-4Y1 Connector
CB703, CB704 13-23905-00 VH 3.96A-5Y1 Connector
16-37210-00
01-37210-00
CONNECTORS
CZ1, CZ2 13-12504-01 4PIN Connector
CZ3, CZ4, CZ5, CZ6, CZ7,
CZ8, CZ9, CZ10
13-12506-00 6PIN Connector
Transistor Assemble Raw PCB
Transistor Assemble PCB with components
TRANSISTOR ASSEMBL BOARD
