NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
C736, C737 06-47012-00 47uF, CD110 100V ±20%
Alu Electrolytic Capacitor
C738, C739 06-10121-02 100uF, CD263 25V ±20%
Alu Electrolytic Capacitor
C112, C213 06-22121-00 220uF, CD110 25V ±20%
Alu Electrolytic Capacitor
C781 06-33111-01 330uF, CD110 16V ±20%
Alu Electrolytic Capacitor
C734, C735 06-10212-01 1000uF, CD294 100V ±20%
Alu Electrolytic Capacitor
C707 06-22211-00 2200uF, CD110 16V ±20%
Alu Electrolytic Capacitor
C748, C749 06-22251-01 2200uF, CD263 50V ±20%
Alu Electrolytic Capacitor
C724, C725, C727, C728 06-10381-02 10000uF, CD294 80V ±20%
Alu Electrolytic Capacitor
RESISTORS
R745 07-10229-00
2R2¡
1/6W ±5% Carbon Film Resistor
R759 07-10103-00
10K¡
1/6W ±5% Carbon Film Resistor
R739, R766, R771, R799 07-10100-10
10¡
1/4W ±5% Carbon Film Resistor
R702 07-10680-10
68¡
1/4W ±5% Carbon Film Resistor
R120 07-10101-00
100¡
1/6W ±5% Carbon Film Resistor
R706, R707, R753, R792,
R793
07-10101-10
100¡
1/4W ±5% Carbon Film Resistor
R127, R227 07-10201-00
200¡
1/6W ±5% Carbon Film Resistor
R783(with 36V relay) 07-10821-10
820¡
1/4W ±5% Carbon Film Resistor
R701, R703, R704, R705,
R708, R716, R717, R718,
R719, R720, R721, R724,
R726, R727, R742, R744
07-10102-10
1K¡
1/4W ±5% Carbon Film Resistor
R772 07-10222-10
2K2¡
1/4W ±5% Carbon Film Resistor
R725, R750, (R783)(with
24V relay)
07-10332-10
3K3¡
1/4W ±5% Carbon Film Resistor
R737 07-10392-10
3K9¡
1/4W ±5% Carbon Film Resistor
R790 07-10512-10
5K1¡
1/4W ±5% Carbon Film Resistor
R788 07-10562-10
5K6¡
1/4W ±5% Carbon Film Resistor
R736 07-10622-10
6K2¡
1/4W ±5% Carbon Film Resistor
R11, R13, R728, R730,
R785, R786, R787, R791,
R778, R780, R782, R784
07-10103-10
10K¡
1/4W ±5% Carbon Film Resistor
R123, R222, R12, R709,
R714, R715, R781, R775,
R776
07-10223-10
22K¡
1/4W ±5% Carbon Film Resistor
R773, R774, R777 07-10563-10
56K¡
1/4W ±5% Carbon Film Resistor
R754 07-10103-00
10K
¡
1/6W ±5% Carbon Film Resistor
R756, R757 07-10104-00
100K¡
1/6W ±5% Carbon Film Resistor
R126, R226, R795 07-10104-10
100K¡
1/4W ±5% Carbon Film Resistor
R752 07-10204-10
200K¡
1/4W ±5% Carbon Film Resistor
R755, R794 07-10224-10
220K¡
1/4W ±5% Carbon Film Resistor
R760, R761 07-10224-00
220K¡
1/6W ±5% Carbon Film Resistor
R743, R796 07-10474-00
470K¡
1/6W ±5% Carbon Film Resistor
R713, R797 07-10474-10
470K¡
1/4W ±5% Carbon Film Resistor
R711 07-21000-10
100¡
1/4W ±1% Metal Film Resistor
R119, R219 07-20221-10
220¡
1/4W ±5% Metal Film Resistor
R733, R735 07-22400-10
240¡
1/4W ±1% Metal Film Resistor
R101, R103, R105, R107,
109, R111, R113, R115,
R118, R201, R203, R205,
R207, R209, R211, R213,
R215, R217
07-20471-00
470¡
1/6W ±5% Metal Film Resistor
R121, R221 07-25620-10
562¡
1/4W ±1% Metal Film Resistor
R740, R741 07-21001-11
1K¡
1/4W ±2% Metal Film Resistor
R732, R734 07-26201-10
6K2¡
1/4W ±1% Metal Film Resistor
R712 07-29101-10
9K1¡
1/4W ±1% Metal Film Resistor
R765, R770 07-21202-11
12K¡
1/4W ±2% Metal Film Resistor
R768, R789 07-23602-10
36K¡
1/4W ±1% Metal Film Resistor
R764, R769 07-22002-10
20K¡
1/4W ±1% Metal Film Resistor
17
