ELECTRICAL PARTS LIST

REF. NO. PART NO.

DESCRIPTION

D719, D720 33-14709-00 4.7V 1/2W Zener Diode

D714 33-16809-00 6.8V 1/2W Zener Diode

D729 33-11000-00 10V 1/2W Zener Diode

D700 33-11300-00 13V 1/2W Zener Diode

D741, D742 33-11800-00 18V 1/2W Zener Diode

D721 33-12400-02 (24V, with 24V relay) 5W Zener Diode

B703, B704 33-31542-00 KBU1504 Rectifier Bridge

B701, B705, B706 33-30142-00 DB104 Rectifier Bridge

TRANSISTORS

Q713 31-00872-00 2SA872AE Transistor

Q703, Q705, Q706, Q707,

Q721, Q723, Q724, Q725,

Q726

31-01015-00 2SA1015GR Transistor

Q710, Q711, Q714 31-01775-00 2SC1775AE Transistor

Q700, Q702, Q704, Q708,

Q720, Q722, Q727, Q729,

Q730

31-01815-00 2SC1815GR Transistor

Q712 31-01220-00 KSA1220AYSTU Transistor

Q701, Q709, Q715 31-02690-00 KSC2690AYSTU Transistor

D702, D703 33-60116-00 BT151-500R SCR

ICS

IC701 03-07805-00 LM7805 IC, Regulator

IC703 03-00317-00 LM317(T) IC, Tunable Regulator

IC704 03-00337-00 LM337(T) IC, Tunable Regulator

IC705 03-00082-00 TL082D IC, OP-AMP

IC706 03-01237-00 uPC1237HA IC,Protect IC

CAPACITORS

C211 05-82922-00 8.2pF 250V ±0.5pF Ceramic Disk Capacitor

C740, C741 05-47022-00 47pF 250V ±20% Ceramic Disk Capacitor

C101, C102, C103, C104,

C105, C106, C107, C108,

C109, C201, C202, C203,

C204, C205, C206, C207,

C208, C209

05-10152-00 100pF 500V ±20% Ceramic Disk Capacitor

C113, C114, C214, C215 05-22122-00 220pF 250V ±20% Ceramic Disk Capacitor

C759, C786 24-10361-05 10nF 63V ±20% Ceramic Disk Capacitor

C705, C708, C710, C714 24-10461-00 0.1uF 63V ±20% Ceramic Disk Capacitor

C782 24-22461-00 0.22uF 63V ±20% Ceramic Disk Capacitor

C719 25-10251-06 1nF, CL11 50V ±20%
