NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
15
IC906 03-02400-00 AT24C01 IC, EEPROM
IC901 03-07400-00 74LS00 N IC, LOGIC IC
IC904, IC905 03-04094-00 HEF4094/CD4094 IC, LOGIC IC
IC902 03-86812-05
Z86E0812PSC/G I
C, MCU used with IC906 AT24C01
IC902 03-86812-06
Z86E0812PSC/G I
C, MCU used with IC906 AT24C01A only
IC903 03-01701-00 GP1UV701QS IC, IR Receiver
IC903 03-00038-40 (or HS0038B4) IC, IR Receiver
CAPACITORS
C902, C903 05-20022-00 20pF
250V ±20% Cermatic Disk Capacitor
C906, C907, C908, C909,
C910, C911, C912, C913,
C914
25-10361-01 10nF, CL11
63V ±10% Metallized Polyester Film Capacitor
C901, C915 24-10461-00 0.1uF
63V ±20%
Monolithic
C904 06-10061-01 10uF, CD110
63V ±20% Alu Electrolytic Capacitor
C905 06-47061-00 47uF, CD110
63V ±20% Alu Electrolytic Capacitor
RESISTORS
R926 07-10220-10
22
1/4W ±5%
Carbon Film Resistor
R901, R935, R936 07-10101-10
100
1/4W ±5%
Carbon Film Resistor
R927, R938 07-10331-10
330
1/4W ±5%
Carbon Film Resistor
R934 07-10821-10
820
1/4W ±5%
Carbon Film Resistor
R900, R902, R903 07-10102-10
1K
1/4W ±5%
Carbon Film Resistor
R923, R933, R944, R945 07-10222-10
2K2
1/4W ±5%
Carbon Film Resistor
R904, R905, R907, R908,
R909, R910, R911, R912,
R913, R914, R915, R916,
R917, R918, R919, R920,
R921, R922, R924, R943
07-10472-10
4K7
1/4W ±5%
Carbon Film Resistor
R930 07-10682-10
6K8
1/4W ±5%
Carbon Film Resistor
R906, R925, R937, R939,
R940, R941, R931
07-10103-10
10K
1/4W ±5%
Carbon Film Resistor
R929 07-10223-10
22K
1/4W ±5%
Carbon Film Resistor
SWITCHS
K909, K906, K908, K905,
K901, K903, K904, K902,
K907
11-04101-00 IT-1102D-1160
Tact Switch
CRYSTALS
X901 04-11202-00
12MHz, HC-49uF
Crystal
CONNECTORS
CZ502 14-37004-00 4PIN, L=260mm
Connector
CZ907 14-37010-01 10PIN, L=170mm
Connector
CZ906 14-37010-00 10PIN, L=550mm
Connector
16-37201-00
Main Board Raw PCB
01-37201-00
Assembled Main Board PCB
DIODES
D705, D706, D707, D708,
D709, D710, D715, D716,
D737, D722, D730, D731,
D732, D733, D734, D735,
D736, D728, D740
33-44148-02 1N4148 Switch Diode
D701, D723, D724, D725,
D726, D727
33-44148-03 1N4148 Switch Diode
D711, D713, D717, D718 33-40021-00 BAV21 Switch Diode
D704 33-25401-01 1N5401 Rectifier Diode
