CONNECTIONS
CZ501 14-37208-00 8P2.54-A50B
Connection
CB502 13-22504-00 XHB 2.54A-4A
Connection
16-37205-00
PRE AMP Module Raw PCB
01-37205-00
Assembled PRE AMP Module PCB
TRANSISTORS
Q804, Q809 31-00209-00 2SK209GR
J-FET
Q801, Q807 31-01312-00 2SA1312GR
Transistor
Q802, Q805, Q808, Q810 31-03324-00 2SC3324GR
Transistor
Q806, Q812 31-01225-00
Transistor
Q806, Q812 31-01215-10
Transistor
Q803, Q811 31-02983-00
Transistor
Q803, Q811 31-01815-10
Transistor
CAPACITORS
C805, C808 26-22051-01 22pF, 0805
50V
±5% Cermatic Capacitor Smd
C801, C803 26-47051-01 47pF, 0805
50V
±5% Cermatic Capacitor Smd
C802, C804 26-10251-01 1nF, 0805
50V
±10% Cermatic Capacitor Smd
C806, C807, C809, C810 26-10451-01 0.1uF, 0805
50V
+80%-20% Cermatic Capacitor Smd
RESISTOR
R804, R808, R819, R820 07-90100-01
10
0805 ±5% Resistor Smd
R821, R822 07-90221-01
220
0805 ±5% Resistor Smd
R806, R815 07-94320-01
432
0805 ±1% Resistor Smd
R801, R802, R809, R811,
R812, R817
07-90102-01
1k
0805 ±58% Resistor Smd
R803, R813 07-90152-01
1k5
0805 ±5% Resistor Smd
R810, R818 07-90183-01
18k
0805 ±5% Resistor Smd
R805, R814 07-90105-01
1M
0805 ±5% Resistor Smd
CONNECTORS
P801 13-12510-01 10PIN
Connector
16-37204-00
Key Raw PCB
01-37204-00 Assembled Key PCB
DIODES
D906, D908, D909, D910,
D911
33-44148-02 1N4148
Switch Diode
D912 33-44148-03 1N4148
Switch Diode
D907 33-16809-00 6V8
Zener Diode
LD908, LD904, LD909,
LD902, LD901, LD912,
LD905, LD903, LD906
33-50550-00 L-513DG
LED Green
LD907, LD911 33-50540-00 L-513AD
LED Red
LED910 33-50525-00 L-519EGFW
LED Dual Color
TRANSISTORS
Q916, Q901, Q902, Q903,
Q904, Q905, Q906, Q907,
Q908, Q909, Q910, Q912,
Q914
31-01815-00 2SC1815GR
Q915, Q913 31-01015-00 2SA1015GR
ICS
(or 2SD1815S)(Complementary pair with 2SB1215S)
2SC2983Y(Complementary pair with 2SA1225Y)
(or 2SB1215S)(Complementary pair with 2SD1815S)
2SA1225Y(Complementary pair with 2SC2983Y)
PRE AMP MODULE(2 PCS)
KEY BOARD
