NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
R467 07-70471-08
T0=80 C degree
PTH9M04BF471TS2F333
PTC
R466 07-70022-09 T0=90 C degree ST-22 90C Thermal breaker
VR402 09-02501-00
500¡
Variable Resistor
VR401 09-02503-00
50K¡
Variable Resistor
INDUCTORS
L401, L402 08-02100-00 10uH
Inductor
CONNECTORS
CZ404 13-23905-00 VH 3.96A-5Y1
Connector
CZ401 13-22504-00 XHB 2.54A-4A
Connector
CZ402 13-22509-00 XHB 2.54A-9A
Connector
TP403-TP404 13-12502-00 2PIN
Connector
TP401, TP402 13-10001-00 1PIN
Connector
16-37203-00
Tone Raw PCB
01-37203-00
Assembled Tone PCB
TRANSISTORS
Q501, Q503 31-01015-00 2SA1015GR
Transistor
Q502, Q504 31-01815-00 2SC1815GR
Transistor
RESISTORS
R520, R521, R522, R523,
R524, R525
07-10222-10
2K2¡
1/4W ±5% Carbon Film Resistor
R515 07-10103-10
10K¡
1/4W ±5% Carbon Film Resistor
R615 07-10103-00
10K¡
1/6W ±5% Carbon Film Resistor
R509 07-10101-00
100¡
1/6W ±5% Carbon Film Resistor
R514, R614 07-20169-00
1.6¡
1/6W ±5% Metal Film Resistor
R505, R605 07-21800-10
180¡
1/4W ±1% Metal Film Resistor
R502, R602, R504, R604 07-23900-10
390¡
1/4W ±1% Metal Film Resistor
R511, R609 07-25900-00
590¡
1/6W ±1% Metal Film Resistor
R507, R607 07-27500-10
750¡
1/4W ±1% Metal Film Resistor
R601, R501 07-21501-10
1K5¡
1/4W ±1% Metal Film Resistor
R606, R506 07-23221-10
3K32¡
1/4W ±1% Metal Film Resistor
R503 07-25101-00
5K1¡
1/6W ±1% Metal Film Resistor
R603 07-25101-10
5K1¡
1/4W ±1% Metal Film Resistor
R510, R610 07-20153-10
15K¡˄Debug part˅
1/4W ±5% Metal Film Resistor
R513 07-20106-00
10M
¡
1/6W ±5% Metal Film Resistor
RV3 09-01203-05 RK16812MGA10(20KBX2) POT
RV1, RV2 09-01103-07 RD163121A023-10KAX2 POT
RV4 09-01203-06 RD163121A020-20KMN POT
CAPACITORS
C511 05-43022-00 43pF
250V ±20% Cermatic Disk Capacitor
C509, C609 05-47122-00 470pF
250V ±20% Cermatic Disk Capacitor
C522 24-10461-00 0.1uF
63V ±20% Cermatic Disk Capacitor
C502, C602 25-10361-04 10nF, CL23B
63V ±10% Metallized Polyester Film Capacitor
C507, C607 25-22312-05 22nF, CBB25
100V ±2% Metallized Polyester Film Capacitor
C508, C608 25-10461-03 0.1uF, CBB25
63V ±2% Metallized Polyester Film Capacitor
C503, C603 25-23461-00 0.23uF, CL23B
63V ±5% Metallized Polyester Film Capacitor
C504, C604 25-95461-00 0.95uF, CL23B
63V ±5% Metallized Polyester Film Capacitor
C520, C521 06-47961-01 4.7uF, CD110
63V ±20% Alu Electrolytic Capacitor
C501, C601 06-22121--00 220uF, CD110
25V ±20% Alu Electrolytic Capacitor
SWITCHS
SW4 11-02202-00 SPUN19K605 Push Switch
TONE BOARD
13
