NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
ICS
4IC1, 4IC2
03-00431-00 TL431/KA431 IC, Regulator
IC401
03-00082-00 TL082D IC, OP-AMP
CAPACITORS
C405, C407 05-22052-00 22pF
500V ±20% Cermatic Disk Capacitor
C402 05-68152-00 680pF
500V ±20% Cermatic Disk Capacitor
C425, C426 05-47152-00 470pF
500V ±20% Cermatic Disk Capacitor
C420 05-22312-00 22nF
100V +50%-20% Cermatic Disk Capacitor
C413, C424, C428 25-10451-03 0.1uF, CL23B
50V ±10% Metallized Polyester Film Capacitor
C418 25-10461-01 0.1uF, CL21
63V ±10% Metallized Polyester Film Capacitor
C409, C410, C416, C417 25-10412-02 0.1uF, CL23B
100V ±10% Metallized Polyester Film Capacitor
C427 25-10561-00 1uF, CL233X
63V ±5% Metallized Polyester Film Capacitor
C401, C403, C404, C421,
C415, C419
06-10051-00 10uF, CD110
50V ±20% Alu Electrolytic Capacitor
C422, C423 06-10012-00 10uF, CD110
100V ±20% Alu Electrolytic Capacitor
C411, C412 06-10121-02 100uF, CD263
25V ±20% Alu Electrolytic Capacitor
C406 06-22260-00 2200uF, CD110
6.3V ±20% Alu Electrolytic Capacitor
RESISTORS
R488, R489, R490, R491 07-10109-10
1¡
1/4W ±5% Carbon Film Resistor
R480, R481, R482, R483,
R484, R485, R486, R487
07-10229-12
2R2¡
1/4W ±5% Carbon Film Resistor
R408, R420, R436, R440 07-10330-10
33¡
1/4W ±5% Carbon Film Resistor
R407, R477 07-10820-10
82¡
1/4W ±5% Carbon Film Resistor
R403, R404, R406, R412,
R414, R428, R473, R474
07-10101-10
100¡
1/4W ±5% Carbon Film Resistor
R447 07-10221-10
220¡
1/4W ±5% Carbon Film Resistor
R401 07-10471-10
470¡
1/4W ±5% Carbon Film Resistor
R411, R415, R446, R461 07-10102-10
1k¡
1/4W ±5% Carbon Film Resistor
R445 07-10122-10
1k2¡
1/4W ±5% Carbon Film Resistor
R475 07-10222-10
2k2¡
1/4W ±5% Carbon Film Resistor
R464 07-10682-10
6k8¡
1/4W ±5% Carbon Film Resistor
R410, R416, R433, R435,
R442, R443
07-10103-10
10k¡
1/4W ±5% Carbon Film Resistor
R462 07-10153-10
15k¡
1/4W ±5% Carbon Film Resistor
R402, R463, R465 07-10223-10
22k¡
1/4W ±5% Carbon Film Resistor
R417 07-21500-10
150¡
1/4W ±1% Metal Film Resistor
R453 07-20243-10
24k
¡
1/4W ±5% Metal Film Resistor
R405, R413 07-20273-10
27K¡
1/4W ±5% Metal Film Resistor
R421, R425, R427 07-20393-10
39K¡
1/4W ±5% Metal Film Resistor
R418 07-20473-10
47K¡
1/4W ±5% Metal Film Resistor
R424, R426 07-20104-10
100K¡
1/4W ±5% Metal Film Resistor
R450 07-20184-10
180K¡
1/4W ±5% Metal Film Resistor
R476 07-20224-10
220K¡
1/4W ±5% Metal Film Resistor
R452 07-20105-10
1M¡
1/4W ±5% Metal Film Resistor
R471, R472 07-28201-20
8K2¡
1/2W ±1% Metal Film Resistor
R419 07-29101-20
9K1¡
1/2W ±1% Metal Film Resistor
R422 07-21002-20
10K¡
1/2W ±1% Metal Film Resistor
R430, R438 07-30339-00
3R3¡
1/2W ±5% Metallized Oxid Film Resistor
R451 07-30220-00
22¡
1/2W ±5% Metallized Oxid Film Resistor
R409, R423 07-38209-00
82¡
1/2W ±2% Metallized Oxid Film Resistor
R432, R441 07-30331-01
330¡
1/2W ±5% Metallized Oxid Film Resistor
R459 07-30100-01
10¡
1W ±5% Metallized Oxid Film Resistor
R429, R437 07-30101-15
100¡
1W ±5% Metallized Oxid Film Resistor
R449, R448 07-30750-01
75¡
1W ±5% Metallized Oxid Film Resistor
R434, R444, R495, R496 07-30472-03
4K7¡
3W ±5% Metallized Oxid Film Resistor
R431, R439 07-50479-01
4R7¡
1/2W ±5% Fusible Resistor
R456, R457 07-50507-05
0.05¡
5W ±5%
CERAMIC CASE
12
