NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
R393 07-20243-10
24k¡
1/4W ±5% Metal Film Resistor
R305, R313 07-20273-10
27k¡
1/4W ±5% Metal Film Resistor
R321, R378, R327 07-20393-10
39k¡
1/4W ±5% Metal Film Resistor
R318 07-20473-10
47k¡
1/4W ±5% Metal Film Resistor
R324, R326 07-20104-10
100k¡
1/4W ±5% Metal Film Resistor
R379 07-20184-10
180k¡
1/4W ±5% Metal Film Resistor
R376 07-20224-10
220k¡
1/4W ±5% Metal Film Resistor
R392 07-20105-10
1M¡
1/4W ±5% Metal Film Resistor
R319 07-29101-20
9k1¡
1/2W ±1% Metal Film Resistor
R322 07-21002-20
10k¡
1/2W ±1% Metal Film Resistor
R330, R338 07-30339-00
3R3¡
1/2W ±5% Metallized Oxid Film Resistor
R309, R323 07-38209-00
82¡
1/2W ±2% Metallized Oxid Film Resistor
R332, R341 07-30331-01
330¡
1/2W ±5% Metallized Oxid Film Resistor
R351 07-30220-00
22¡, 0.5W, ±5%
1/2W ±5% Metallized Oxid Film Resistor
R359 07-30100-01
10¡
1W ±5% Metallized Oxid Film Resistor
R348, R349 07-30750-01
75¡
1W ±5% Metallized Oxid Film Resistor
R358 07-30101-01
100¡
1W ±5% Metallized Oxid Film Resistor
R329, R337 07-30101-15
100¡
1W ±5% Metallized Oxid Film Resistor
R334, R344, R395, R396 07-30472-03
4k7¡
3W ±5% Metallized Oxid Film Resistor
R331, R339 07-50479-01
4R7¡
1/2W ±5% Fusible Resistor
R356, R357 07-50507-05
0.05¡
5W ±5%
CERAMIC CASE
R367 07-70471-08
T0=80 C degree
PTH9M04BF471TS2F333
PTC
R366 07-70022-09 T0=90 C degree ST-22 90C Thermal breaker
VR302 09-02501-00
500¡
Variable Resistor
VR301 09-02503-00
50k¡
Variable Resistor
INDUCTORS
L301, L302 08-02100-00 10uH
Inductor
CONNECTORS
CZ304 13-23905-00 VH 3.96A-5Y1
Connector
CZ301 13-22503-00 XHB 2.54A-3A
Connector
CZ302 13-22509-00 XHB 2.54A-9A
Connector
TP303-TP304 13-12502-00 2PIN
Connector
TP301, TP302 13-10001-00 1PIN
Connector
16-37202-02
R Channel Raw PCB
01-37202-02
Assemblied R Channel PCB
DIODES
D403, D404, D405, D406,
D409
33-44148-02 1N4148
Switch Diode
D407, D408 33-40021-01 BAV21
Switch Diode
D402 33-11800-00 18V
1/2W Zener Diode
D401 33-11800-01 18V
1/2W Zener Diode
TRANSISTORS
Q401, Q406, Q407, Q429 31-00872-00 2SA872A E
Transistor
Q405, Q409, Q416, Q426 31-01015-00 2SA1015GR
Transistor
Q402, Q403, Q404, Q430 31-01775-00 2SC1775A E
Transistor
Q408, Q412, Q425 31-01815-00 2SC1815GR
Transistor
Q431 31-02878-00 2SC2878A
Transistor
Q410, Q413, Q418, Q438 31-00649-00 2SB649A C
Transistor
Q411, Q414, Q417, Q437 31-00669-00 2SD669A C
Transistor
Q415 31-02690-00 KSC2690A Y
Transistor
Q419, Q421, Q423, Q427 31-01943-00 2SA1943 O
Transistor
Q420, Q422, Q424, Q428 31-05200-00 2SC5200 O
Transistor
R CHANNEL AMP BOARD
11
