NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
16-37202-01
L Channel Raw PCB
01-37202-01
Assembled L Channel PCB
DIODES
D303, D304, D305, D306,
D309
33-44148-02 1N4148
Switch Diode
D302 33-11800-00 18V
1/2W Zener Diode
D301 33-11800-01 18V
1/2W Zener Diode
D307, D308 33-40021-01 BAV21
Switch Diode
TRANSISTORS
Q329, Q301, Q306, Q307 31-00872-00 2SA872A E
Transistor
Q305, Q309, Q316, Q326 31-01015-00 2SA1015GR
Transistor
Q302, Q303, Q304, Q330 31-01775-00 2SC1775A E
Transistor
Q308, Q312, Q325 31-01815-00 2SC1815GR
Transistor
Q310, Q313, Q318, Q338 31-00649-00 2SB649A C
Transistor
Q311, Q314, Q317, Q337 31-00669-00 2SD669A C
Transistor
Q315 31-02690-00 KSC2690A Y
Transistor
Q319, Q321, Q323, Q327 31-01943-00 2SA1943 O
Transistor
Q320, Q322, Q324, Q328 31-05200-00 2SC5200 O
Transistor
ICS
3IC1, 3IC2 03-00431-00 TL431/KA431 IC, Regulator
IC301 03-00082-00 TL082D IC, OP-AMP
CAPACITORS
C305, C307 05-22052-00 22pF
500V ±20% Cermatic Disk Capacitor
C302 05-68152-00 680pF
500V ±20% Cermatic Disk Capacitor
C313, C314 05-47152-00 470pF
500V ±20% Cermatic Disk Capacitor
C320 05-22312-00 22nF
100V +50%-20% Cermatic Disk Capacitor
C315, C319, C324 25-10451-03 0.1uF
50V ±10% Metallized Polyester Film Capacitor
C318 25-10461-01 0.1uF, CL21
63V ±10% Metallized Polyester Film Capacitor
C309, C310, C316, C317 25-10412-02 0.1uF, CL23B
100V ±10% Metallized Polyester Film Capacitor
C327 25-10561-00 1uF, CL233X
63V ±5% Metallized Polyester Film Capacitor
C301, C303, C304, C321,
C325, C326
06-10051-00 10uF, CD110
50V ±20% Alu Electrolytic Capacitor
C322, C323 06-10012-00 10uF, CD110
100V ±20% Alu Electrolytic Capacitor
C311, C312 06-10121-02 100uF, CD263
25V ±20% Alu Electrolytic Capacitor
C306 06-22260-00 2200uF, CD110
6.3V ±20% Alu Electrolytic Capacitor
RESISTORS
R388, R389, R390, R391 07-10109-10
1¡
1/4W ±5% Carbon Film Resistor
R380, R381, R382, R383,
R384, R385, R386, R387
07-10229-12
2R2¡
1/4W ±5% Carbon Film Resistor
R308, R320, R336, R340 07-10330-10
33¡
1/4W ±5% Carbon Film Resistor
R377, R307 07-10820-10
82¡
1/4W ±5% Carbon Film Resistor
R303, R304, R306, R312,
R314, R328, R373, R374
07-10101-10
100¡
1/4W ±5% Carbon Film Resistor
R347 07-10221-10
220¡
1/4W ±5% Carbon Film Resistor
R301 07-10471-10
470¡
1/4W ±5% Carbon Film Resistor
R311, R315, R346, R361 07-10102-10
1k¡
1/4W ±5% Carbon Film Resistor
R345 07-10122-10
1k2¡
1/4W ±5% Carbon Film Resistor
R375 07-10222-10
2k2¡
1/4W ±5% Carbon Film Resistor
R364 07-10682-10
6k8¡
1/4W ±5% Carbon Film Resistor
R310, R316, R333, R335,
R342, R343
07-10103-10
10k¡
1/4W ±5% Carbon Film Resistor
R362 07-10153-10
15k¡
1/4W ±5% Carbon Film Resistor
R302, R363, R365 07-10223-10
22k¡
1/4W ±5% Carbon Film Resistor
R317 07-21500-10
150¡
1/4W ±1% Metal Film Resistor
DESCRIPTION
L CHANNEL AMP BOARD
10
