EXPLODED VIEW PARTS LIST
REF. NO PART NO. DESCRIPTION Qty. REF. NO PART NO. DESCRIPTION Qty.
C001 67-005010-0 Transformer Shielding Box 1 F007 76-001001-0 IR Lens 1
C002 01-37205-10 Assemblied Pre Amp Module 2 F008 76-003001-0 LED Lens 12
C003 18-37371-22 Transformer C Version 1 F009 77-002002-1 Tone Defeat Button 1
18-37371-12 Transformer AH Version 1 F010 73-014001-1 Tone Knob 3
C004 66-005007-0 Metal Disc 1 F011 77-001001-1 Tone Control Lozenge 1
C005 94-005004-1 Transformer Disc Label 1 F012 73-014002-1 Volume Knob 1
C006 66-018001-1 Chassis 1 F013 74-001002-1 Input Button (3P) 3
C007 66-005004-0 Base Cover 1 F014 75-005001-0 Sleeve(1P) 4
C008 75-010004-1 Foot 4 F015 01-37204-00 Assembled Key Board 1
C009 78-001002-0 Foot Pad 4 F016 66-018003-0 Headphone Bracket 1
C010 69-005006-0 BDP Pin Big 4 F017 66-005005-0 IR Bracket 1
C011 69-002004-0 BDP Pin Small 4 F018 75-003003-0 Bracket 2
C012 70-004003-1 Heat Sink Small B 2 F019 75-003002-0 Sleeve(1P) 1
C013 01-37203-00 Assembled Tone PCB 1 F020 77-018001-0 Knob Volume lozenge 1
C014 70-018001-0 Main Heatsink 2 F021 75-003001-0 Sleeve(7P) 1
C015 85-005001-0 PCB Spacer 10 F022 66-018002-0 Subfascia 1
C016 01-37202-02 Assembled R Channel AMP PCB 1
C017 66-018005-0 Tem. SW Clamper 2 R001 67-018006-0 Rear Panel(C) 1
C018 78-005005-0 Insulated Cashion 16 67-018005-0 Rear Panel(AH) 1
C019 01-37206-00 Assembled Relay PCB 1 R002 18-37060-01 Standby Transformer 1
C020 66-005009-0 Transistor Clamping 16 R003 01-37208-01 Assembled AC Inlet PCB (C Version) 1
C021 70-018003-1 Heatsink C 4 01-37208-02 Assembled AC Inlet PCB (AH Version) 1
C022 78-005002-0 Insluation Cushion(Small) 9
C023 01-37201-00 Assembled Main PCB 1 S001 64-110070-0 Bolt, GB5781, M10X70 1
C024 01-37202-01 Assembled L Channel AMP PCB 1 S002 63-011020-2 Washers, GB97-87φ10 3
S003 63-021030-0 Spring Washers, GB93φ10 2
M001 70-018004-0 Module Lid 2 S004 62-011002-0 Nuts, GB6170, M10 2
M002 78-018001-0 Insulated Cashion 4 S005 61-062108-0 Self Taping Screws, STF2X8-0 4
M003 66-018004-0 Trans Clamp (Module) 4 S006 61-023208-0 Self Taping Screws, BTB3X8 32
M004 01-37205-00 Assembled Pre Amp Module PCB 2 S007 61-024108-0 Self Taping Screws, STB3X8 11
M005 70-018002-0 Module heatsink box 2 S008 61-084108-0 Self Taping Screws, STPW4X8 6
S009 61-023106-0 Self Taping Screws, STB3X6 44
T001 67-018004-0 Top Cover 1 S010 61-022204-6 Self Taping Screws, BTB2.6X4 1
S011 61-023212-0 Self Taping Screws, BTB3X12 2
F001 67-018003-0 Fascia 1 S012 61-223514-0 Hex Screws, GB70, 3X14 16
F002 67-018001-0 End Cap L 1 S013 61-022205-6 Self Taping Screws, BTB2.6X5 2
F003 67-018002-0 End Cap R 1 S014 61-022206-6 Self Taping Screws, BTB2.6X6 14
F004 77-002002-1 Power Button 1 S015 61-083515-0 Machine Screws, MPW3X15 2
F005 77-001007-1 Power Button Bezel 1 S016 61-033420-0 Self Taping Screws, PTP3X20 10
F006 77-005001-1 Input Button Lozenge 1 S017 61-022206-8 Self Taping Screws, BTB2.6X8 18
To Next Page
