NAD C 372 Service Manual

ELECTRICAL PARTS LIST
REF. NO. PART NO.
DESCRIPTION
16-37206-00 Relay Board Raw PCB
01-37206-01 Relay Board with components (C Version)
01-37206-02 Relay Board with components (AH Version)
DIODES
D712 33-44148-02 1N4148 Switch Diode
CAPACITORS
C702 05-47242-00 4.7nF, 400V, ±20%, CT81 High-Voltage Ceramic Capacitor
RELAYS
RL701 12-02101-01 DH5D1-O(M) TV-8 Relay
FUSES
F701 20-20000-01 HF-003-1 Fuse Holder
20-12402-01
20-12632-01
CONNECTIONS
CZ706 13-22502-00 XHB 2.5A-2A Connector
CB709 13-23903-01 Connector
CB707, CB711 13-23905-01 Connector
OTHERS
J701 21-06121-01 L=12.5(C Version) Link
21-06201-00 L=20(AH Version) Link
16-37207-00 Main Switch Board Raw PCB
01-37207-00
CAPACITORS
C701 05-47242-00 4.7nF, 400V, ±20%, CT81 High-Voltage Ceramic Capacitor
SWITCHS
SW1 11-01101-00 SFDFA1117U Power Switch
CONNECTONS
CB710 13-23903-01
16-37208-00 AC Inlet Board Raw PCB
01-37208-00 AC Inlet Board PCB with components
CONNECTIONS
17-07102-00 GSP1.9500.1/R-30190 2PIN AC Inlet
17-07002-20 A3-02-D006-0P(C Version) AC Outlet
17-07002-12 AC Outlet
CZ710 13-23905-01 Connector
16-37209-00 Headphone Socket Board Raw PCB
01-37209-00
CONNECTORS
JK701 17-02001-00 PH-2ASW(with nut and washer) Phone Jack
VH 3.96A-5Y1 (Removed the 2nd and 4th pin˅
A2-02-D003-0P(AH Version)
VH 3.96A-5Y1 (Remover the 2nd and 4th pin˅
Headphone Socket Board PCB with components
VH 3.96A-3Y1 (Removed the middle pin˅
MAIN SWITCH BOARD
HEADPHONE SOCKET BOARD
VH 3
.
96A
-
3Y1 (Removed the middle
pin
˅
T6.3AL/250V (AH Version)
T4.0AL/250V (C Version)
RELAY BOARD
AC INLET BOARD
Main Switch Board PCB with components
19
