SPECIFICATIONS
PRE-AMP SECTION
Line level inputs (Disc, CD, Video, Aux, Tuner, Tape1, Tape2)
Input impedance (R and C) 200kΩ + 320pF
Input sensitivity (ref. rated power) 220mV
Maximum input signal 6V
Signal / Noise ratio A-weighted
1
93.0dB ref. 1W
Signal / noise ratio pre-amp out, A-weighted 106dB ref. 500mV
Frequency response 20Hz - 20kHz <±0.1dB (Tone defeat on)
<±0.5dB (Tone defeat off)
THD + Noise, SMPTE IM < 0.01% at 5V out
Line level outputs
Output impedance Pre-out 80Ω
Tape Source Z + 1kΩ
Maximum output level Pre-out >12V
Tape >10V
Tone controls
Treble ±5dB at 10kHz
Bass ±8dB at 100Hz
Trigger out
Input resistance >10kΩ
Input voltage Minimum 5V
Output resistance <30W
Output current 200mA
Output voltage 12V
POWER AMP SECTION
Continuous output power into 8Ω
2
50W (17dBW)
Rated distortion (THD 20Hz - 20kHz) 0.03%
Clipping power (maximum continuous power per channel 4Ω and 8Ω) 68W
IHF Dynamic headroom 8Ω +3.4dB
4Ω +5.0dB
IHF dynamic power (maximum short term power per channel) 8Ω 110W (20.4dBW)
4Ω 160W (22.0dBW)
2Ω 210W (23.2dBW)
Damping factor (ref. 8Ω, 1kHz) >160
Input impedance (R & C) 20kΩ + 470pF
Input sensitivity (rated output into 8Ω) 630mV
Voltage gain 29dB
Frequency response 20Hz - 20kHz 29dB
Signal/noise ratio, A-weighted ref. 1W 100dB
ref. 50W 117dB
THD + Noise
3
<0.03%
SMPTE IM
4
<0.01%
IHF IM
5
<0.01%
Headphone output impedance 220Ω
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 435 x 100 x 290mm
Net weight 6.5kg (14.3lb)
Shipping weight 8kg (17.6lb)
1 From CD input to speakers output, volume setting for 500mV in, 8Ω 1W out
2 Minimum power per chnnel, 20Hz - 20kHz, both channels driven with no more than rated distiortion.
3 Total harmonic distortion, 20Hz - 20kHz from 250mW to rated output
4 Intermodulation distortion, 60Hz - 7kHz, 4:1, from 250mW to rated output
5 CCIF IM distortion, 19 + 20kHz rated output
Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.
Dimension depth excludes terminals, sockets, controls and buttons.
