NAD C720BEE - Tuner Section; Physical Specifications

13
ENGLISH
FRANÇAISDEUTSCHNEDERLANDSESPAÑOL
ITALIANO
PORTUGUÊS
SVENSKA
TUNER SECTION
Input sensitivity Mono: 16.1dBf
50dB Stereo: 36.1dBf
Harmonic Distortion; FM Mono: 0.3%
Harmonic Distortion; FM Stereo 0.5%
Signal / noise; Mono 60dB
Signal / noise; Stereo 55dB
Stereo separation at 1kHz; 40dB
Frequency Response; ± 1.5dB 30Hz - 15kHz
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 435 x 147 x 387mm
Net weight 8.7kg (19.2lb)
Shipping weight 11.4kg (25.1lb)
1
From CD input to speakers output, volume setting for 500mV in, 8Ω 1W out
2
Minimum power per chnnel, 20Hz - 20kHz, both channels driven with no more than rated distiortion.
3
Total harmonic distortion, 20Hz - 20kHz from 250mW to rated output
4
Interrmodulation distortion, 60Hz - 7kHz, 4:1, from 250mW to rated output
5
CCIF IM distortion, 19 + 20kHz 250mV to rated output
SPECIFICATIONS
