3-49
SECTION 3
ELECTRICAL PARTS LIST
Numbering System of Resistor Numbering System of Capacitor
Example Example
KRD
Type
25
Wattage
F
Shape
J
Tolerance
101
Value
KCKR
Type
1H
Voltage
101
Value
K
Tolerance
B
Peculiarity
Resistor Type Wattage Tolerance
KRD: Carbon 20:1/5W F:= ±1%
KRG: Metal Oxide 25:1/4W J:= ±5%
50:1/2W K:= ±10%
1:1W
KRF: Metal Cement 2:2W
KRQ: Fusible 3:3W
Capacitor Type
Voltage
Tolerance
ECEA Type Other
KCB:Ceramic 0J:6.3V 1H:50V DC C: ±0.25pF
KCC:Ceramic 1A:10V 1:125V DC G: ±2%
KCK:Ceramic 1C:16V KC:400V AC J: ±5%
KCQI:Polyester 1E:25V 25:250V AC K: ±10%
KCQP:Polypropylene 1H:50V Z: +80%, –20%
KCQS:Polystyrol 1V:35V
KCEA:ELECT 2A:100V
KCF:SEMI
KCFE:FILM
Notes : • Part numbers are indicated for most mechanical parts.
Please use this part number for parts order.
• The unit of resistance is OHM (Ω)
K=1000 (Ω), M=1000 (KΩ)
• The unit of capacitance is MICROFARAD (µF)
P=10
-6
µF
RESISTORS AND CAPACITORS
MAIN B`D(KUP11395-1,2,3)
PCB1 KUP11395-1 PCB , MAIN L75
C271 KCEA1HH1R0T CAP , ELECT 1.0UF 50V
C272 , C273 KCCT1H220JC CAP , CERAMIC 22PF 50V J
C274 KCKT1H101KB CAP , CERAMIC 100PF 50 K
C275 KCEA1HHR47T CAP , ELECT 0.47UF 50V
C276 , C277 KCEA1EH470T CAP , ELECT 47UF 25V
C278 KCCT1H100DC CAP , CERAMIC 10PF 50V D
C279 KCCT1H560JC CAP , CERAMIC 56PF 50V J
C280 KCEA1HH1R0T CAP , ELECT 1.0UF 50V
C281 KCKT1H181KB CAP , CERAMIC 180PF 50V J
C282 KCQI1H682JZT CAP , MYLAR 6800PF 50 J
C283 KCEA1HH1R0T CAP , ELECT 1.0UF 50V
C284 KCKT1H223ZF CAP , CERAMIC 0.022UF 50V J
C285 , C286 KCCT1H270JC CAP , CERAMIC 27UF 50V J
C287 KCKT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C288 KCEA1CH101T CAP , ELECT 100UF 16V
C290 KCEA1AH471T CAP , ELECT 470UF 10V
C912 , C913 KCEA1EH101T CAP , ELECT 100UF 25V
C914 , C915 KCKT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C916 , C917 KCKT1HH100T CAP , ELECT 10UF 50V
C918 , C919 KCEA1CH101T CAP , ELECT 100UF 16V
C920 KCEA1AH471T CAP , ELECT 470UF 10V
C921 , C923 KCKT1H223ZF CAP , CERAMIC 0.022UF 50V Z
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
