3-51
CN51 , CN52 BJP06GA130ZK CONNECTOR (SOCKET) TAC-L06X-A3
CN61 , CN62 BJP06GA130ZK CONNECTOR (SOCKET) TAC-L06X-A3
CN71 , CN72 BJP06GA130ZK CONNECTOR (SOCKET) TAC-L06X-A3
CN75 BJP13GA98ZM CONNECTOR (SOCKET) TAC-L13X-A3
CN76 KJP03GA98ZM WAFER MOLEX35336-0310
CN78 KJP04GA01ZM WAFER MOLEX5276-04A
C901 , C902 KCET63VAH123N CAP , ELECT 12000UF/63V
C903 , C904 KCEA1VAHS222E CAP , ELECT 2200UF/35V
C905 KCEA1CH332E CAP , ELECT 3300UF 16V
C922 KCEA1CH222E CAP , ELECT 2200UF 16V
IC27 BVIAN2024V I.C , OSD LC74763-9730
RY79 BSL4A004ZU RELAY OSD-SS-212DM3
R908 , R909 KRG2ANJ470H RES , METAL OXIDE FILM 47 OHM 2W J
R912 KRG1ANJ470H RES , METAL OXIDE FILM 47 OHM 1W J
S799 KST1A010Z SW , TACT
X271 KOX17744D220F CRYSTAL 17.744MHz HC-49/U
PCB2 KUP11395-2 PCB , TRANS
C906 , C907 KCFE1J473JBT CAP , FILM 0.047UF 63V J
C924 KCFE1J124JBT CAP , FILM 0.12UF 63V J
F903 , F904 KBA2C8000TLU FUSE 51S 8A
R913 KRD25TJ103T RES , CARBON 10K OHM 1/4W J
D901 BVDGBJ1504 DIODE , BRIDGE GBT1504
PCB3 KUP11395-3 PCB , PSU
C908 ~ C911 KCFEJ124JBT CAP , FILM 0.12UF 63VJ
C952 KCEA1HH100T CAP , FILM 10UF 50V
C953 KCEA1CH101T CAP , FILM 100UF 16V
C954 KCEA1HH470T CAP , FILM 47UF 50V
C955 KCEA1HH4R7T CAP , FILM 4.7UF 50V
C956 KCEA1HH100T CAP , FILM 10UF 50V
D902 ~ D909 KVD1N4003ST DIODE 1N4003
D951 KVD1N4003ST DIODE 1N4003
D952 KVDMTZJ6.2BT DIODE , ZENER 6.2V 1/2W
D953 KVD1N4003ST DIODE 1N4003
D954 KVDMTZJ33BT DIODE , ZENER 33V 1/2W
D956 KVDMTZJ6.2BT DIODE , ZENER 6.2V 1/2W
Q951 KVTKSC2316YT T.R KSC2316Y
Q952 KVTKSA1175YT T.R KSA1175Y
R951 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
R952 , R953 KRD20TJ560T RES , CARBON 56 OHM 1/4W J
R954 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
CN94 KJP09GA01ZM WAFER MOLEX 5267-09A
CN96 KJP06GA01ZM WAFER MOLEX 5267-06A
CN97 KJP03GA90ZM WAFER MOLEX 35313-0310
CN98 KJP08GB03ZM WAFER MOLEX 5268-08A
R901 ~ R904 KRQ1CJR47 RES , FUSE 0.47 OHM 1W J
FRONT B'D (KUP11396- 1,2,3,4,5,7,8)
PCB1 KUP11396-1 PCB , U-COM
C801 , C802 KCEA1VKS100T CAP , ELECT 10UF 35V
C803 , C804 KCBS1H101KBT CAP , CERAMIC 100PF 50V K
C805 ~ C808 KCEA1VKS100T CAP , ELECT 10UF 35V
C809 , C810 KCFE1J472JBT CAP , FILM 4700PF 63V J
C811 , C812 KCFE1J223JBT CAP , FILM 0.022UF 63V J
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
