NAD L75 - Page 44

3-58
R712 ~ R714 KRD20TJ561T RES , CARBON 560 OHM 1/5W J
R715 , R716 KRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R717 , R718 KRD20TJ561T RES , CARBON 560 OHM 1/5W J
R719 , R820 KRD20TJ223T RES , CARBON 22K OHM 1/5W J
R721 KRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R722 KRD20TJ561T RES , CARBON 560 OHM 1/5W J
R723 KRD20TJ123T RES , CARBON 12K OHM 1/5W J
R724 , R725 KRD20TJ101T RES , CARBON 100 OHM 1/5W J
R726 ~ R728 KRD20TJ820T RES , CARBON 82 OHM 1/5W J
R729 , R730 KRD20TJ2R2T RES , CARBON 2.2 OHM 1/4W J
R732 , R733 KRD20TJ102T RES , CARBON 1K OHM 1/4W J
R734 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
R735 KRD20TJ103T RES , CARBON 10K OHM 1/5W J
BN61 , BN62 BJP06GB131ZK CONNECTOR (PLUG) TAC-L60P-B3
BN71 BJP06GB131ZK CONNECTOR (PLUG) TAC-L60P-B3
BN74 KJP10GB99ZM WAFER MOLEX 35237-1010
C613 ~ C616 KCEA1JAHS471E CAP , ELECT AHS 470UF 63V
C707 , C708 KCEA1JAHS471E CAP , ELECT AHS 470UF 63V
Q615 , Q616 BVT2SA13600 T.R 2SA13600
Q617 , Q618 BVT2SC34230 T.R 2SC34230
Q619 , Q620 KVT2SD1763AE T.R 2SD1763AE
Q621 , Q622 KVT2SB1186AE T.R 2SB1186AE
Q708 BVT2SA13600 T.R 2SA13600
Q709 BVT2SC34230 T.R 2SC34230
Q710 KVT2SD1763AE T.R 2SD1763AE
Q711 KVT2SB1186AE T.R 2SB1186AE
R661 , R662 KRF5EKR22H RES , CEMENT 0.22 OHM 5W K
R671 , R672 KRF5EKR22H RES , CEMENT 0.22 OHM 5W K
R731 , R736 KRF5EKR22H RES , CEMENT 0.22 OHM 5W K
HEAT SINKASS'Y (KMYL75)
ASS'Y 1 KDD1A013WA FAN ASS'Y
BDMMDN4RB4MRC MOTOR BDMMDN4RB4MRC
KDD1A013 FAN A3-96-2231
KWBIC002100BI WIRE ASS'Y
ASS'Y 2 KMY1A165ZA HEAT SINK ASS'Y(F)
KMY1A165 SINK , HEAT(F)
Q613 , Q614 KVT2SC4147V T.R , (BIAS) 2SC4137V
Q623 , Q624 KVT2SC4468-OKM T.R , POWER 2SC4468
Q625 , Q626 KVT2SA1695-OKM T.R , POWER 2SA1695
Q707 KVT2SC4137V T.R , (BIAS) 2SC4137V
Q712 BVT2SC4468-OKM T.R , POWER 2SC4468
Q713 BVT2SA1695-OKM T.R , POWER 2SA1695
ASS'Y 3 KMY1A166ZA HEAT SINK ASS'Y(R)
KMY1A166 SINK , HEAT(R)
Q513 , Q514 KVT2SC4137V T.R , (BIAS) 2SC4137V
Q523 , Q524 BVT2SC4468-OKM T.R , POWER 2SC4468
Q525 , Q526 BVT2SA1695-OKM T.R , POWER 2SA1695
TH71 KRTP43T7D330B THERMAL SENSOR , POSISTOR P43T7D330BW1.5
POWER B'D ( KUP11431-1,2,3,4)
PCB1 KUP11431-1 PCB , SPEAKER
C521 , C522 KCQI1H473JZT CAP , MYLAR 0.047UF 50V J
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
