OVERALL SPECIFICATIONS
Line Level Input
Input impedance (R and C) 56 kΩ + 220 pF
Input sensitivity 40 mV (ref. 500 mV out)
Maximum input signal >8 Vrms
Signal/Noise ratio, A-weighted >90 dB (ref. 500 mV in 500 mV out, volume set to unity gain)
>80 dB (ref. 2 V out, Volume maximum)
Channel Separation >70 dB (ref. 1 kHz/10 kHz)
Frequency response ±0.3 dB (ref. 20 Hz - 20 kHz, Tone Controls - On)
±0.3 dB (ref. 20 Hz - 20 kHz, Tone Controls - O)
Frequency response (subwoofer out) 10 - 200Hz (ref. -3 dB)
Output
Maximum output level >8 Vrms into 600 Ω
THD (CCIF IMD, DIM 100) <0.005% (ref. 20 Hz - 20 kHz, 2 V out)
Balanced >2 Vrms
Standby mode <0.5 W
Tone Controls
Treble ±10 dB at 10 kHz (ref. 2V in 2V out)
Bass ±10 dB at 100 Hz (ref. 2V in 2V out)
USB Input
Digital USB Front/Digital USB Back (USB Type A) MP3/WMA: 48 kHz
FLAC: 24 bit/48 kHz
Computer (USB Type B) 24 bit/192 kHz PCM content from PC or MAC
Digital Input (Coaxial, Optical, AES/EBU)
Input impedance Coaxial : 75 ohms
AES/EBU : 110 ohms
Sample rate 32 kHz to 192 kHz
Frequency response ±0.5dB (ref. 20 Hz – 96 kHz @192 kHz)
Channel separation >75dB (ref. 1/3 rated power, 10 kHz 4 ohms)
DIMENSION AND WEIGHT
Unit dimensions (W x H x D) * 435 x 133 x 383 mm
17 / x 5 / x 15 / inches
Shipping weight 14.5 kg (32.0 lbs)
* - Gross dimension include feet, front panel and rear panel extensions (knobs, buttons, speaker terminals, sub fascia, etc.).
Specifications are subject to change without notice. For updated documentation and features, please check out www.NADelectronics.com for the latest information about M12.
