NAD S250 - Page 13

Location Part Number Descri
p
tion
Q10,Q26 4860-8890-0 TR MPSA06 VCE 80V NS
Q11,Q27 4860-8910-0 TR MPSA56 VCE 80V NS
VR
VR71 4750-9606-1 VR RK09K111 50KA LM=25mm
SVR27 4755-1026-3-14 SVR 1K EVM-31G 6mm DUST
FUSE
F1,F2*AH 5120-0040-0 FU T6.3A 250V 5X20 UL
F1,F2*C 5120-0025-0 FU T6.3A HBC 5X20
MISCELLANEOUS
J1 2101-2181-0 CENTER HEADER 3.96MM
FH1,FH2 4132-1011-0 FUSE HOLDER
TP2,TP1 4132-1071-0 TERMINAL PIN
1007 4134-9241-0 GROUND TERMINAL
R79 8910-0491-0 NTC THERMISTOR 1K
(
B
)
POWER SUPPLY PCB
PCB ASSEMBLY
1100*AH PCB-N0920C-PSU PCB ASSY POWER SUPPLY
1100*C PCB-N0921C-PSU PCB ASSY POWER SUPPLY
CAPACITORS
C103 150F-104K-5-II CC 50V 0.1uF 10% RL 5x5
C4-C7 150N-103M-5-SS CC 1KV 0.01u 20% RL
C2,C3 153R-104J-5-YRM CM 250V 0.1u 5% RL
C102 157E-477M-5-SXK CE 25V 470UF 20% RL
C11,C12 157H-106M-5-OVH CE 100V 10u 20% RL
C10 157H-475M-5-IUC CE 100V 4.7UF 20% RL
C1 8910-0049-0 CAP400V 4700P
C8,C9 8910-0490-0 CE 80V 33000uF 20%
DIODES
D102
4804
-
0010
-
2
DIODE
1N4001
AT
D2,D3 4804-0040-1 DIODE IN4004 AL
D103,D104 4804-1480-2 DIODE 1N4148 AT
D105 4837-5B61-2 DZ 1/2W 5.45-5.73 ROHM
D10-D13 4838-16V6-2 DZ 1W 16V AT TEMIC
D1 4840-7100-0 BRIDGE RECTIFIER MP2540W
TRANSFORMER
T102 1806-3520-0 TRANS EI35 115/230V DC
Location Part Number Descri
p
tion
TERMINAL
0103 2113-1144-0 AC INLET
J17-J19,M1-M6,PSL, 2101-1231-0 SPADE TERMINAL 6.3X0.8
PSN,S1-S6,SS1,SS2,
J1-J5 2101-2171-0 PCB CONN.
(
CENTER 3.96MM
J28 2102-021S-004 2P ST.WAFER
J27 2102-031S-004 3 PIN ST. WAFER
J26 2102-081S-004 WAFER 8P P2.5 ST.
IC
U103 3130-0640-0 IC NJM78L05A 826
U101 3131-6720-0 IC TLP3063 PHOTO TRIAC
U102 3131-6730-0 IC HFE 4011BP QUADRUPLE
RESISTOR
R105 4715-010A-2 RMF 1/4W 1R 1% AT
R2,R3 4715-100J-2-P RMF 1/4W 10R 5% AT FP
R103,R106,R107 4715-102A-2 RMF 1/4W 1K 1% AT
R108,R112 4715-103A-2 RMF 1/4W 10K 1% AT
R1,R6 4715-301J-2-P RMF 1/4W 300R 5% AT FP
R102 4715-330A-2 RMF 1/4W 33R 1% AT
R9 4715-391A-2 RMF 1/4W 390R 1% AT
R104,R111 4715-561A-2 RMF 1/4W 560R 1% AT
R101 4718-6R8J-1-X RMF 1W 6.8R 5% AL METAL
R4,R5,R7 4719-103J-1-X RMF 2W 10K 5% AL METAL
R8,R10 4719-392J-1-X RMF 2W 3.9K 5% AL METAL
R11,R12 471G-751A-2-E RMF 0.6W 750R 1% AT
TRANSISTOR/TRIAC
Q102 4860-0700-5 TR 2SC1815
(
G.R
)
RL
Q101 4860-5350-5 TR BTA26A-600B RL
FUSE
F1*C 5120-0025-0 FU T6.3A HBC 5X20
F1*AH 5120-0506-0 FUSE T12.5A 250V UR
HEATSINKS
1101 5400-9071-0 HEAT SINK
1102 5400-9081-0 HEATSINK FOR BRIDGE
MISCELLANEOUS
0116 5200-3441-0 POWER SWITCH DPST
1108 1660-0700-0 INSULATING BOOT
(
ID=14
)
FL1*C 1806-3519-0 EMI FILTER 20DBAG5
1109 3100-5491-0 INSULATION SHEET 112X27
FH1*AH 4131-9131-0 FUSE HOLDER 6.5MM PITCH
