NAD T 762 - Surround; Back Surround Amplifier

33
SURROUND / BACK SURROUND AMPLIFIER
RN
RN
RN
E C B
2SC2362
E C B
2SA1015 2SA1815
B C E
2SA1606 2SC4159
B C E
2SA2031 2SC5669
E C B
2SD600K 2SD631K
DTC123ESA
E C B
E C B
2SA1016K
2SC2362
E C B
2SC1740S
E C B
2SB772
RESISTORS : RN-CERAMIC CASE, MO-METAL OXIDE, UNLESS OTHERWISE SPECIFIED ARE CARBON FILM. NOTE: 1. RESISTORS, UNLESS OTHERWISE SPECIFIED, ARE 1/6W, 5%.
2. ALL CERAMIC CAPACITORS, UNLESS OTHERWISE SPECIFIED, ARE 50V, 10%. 3. COMPONENTS MARKED “
” ARE SAFETY CRITIAL PARTS.
