EXPLODED VIEW PARTS LIST
Item Part No. Description Qty.
1 10-0752001-00-10 WINDOW LENS 1
2 10-0752002-71-00 VOLUME KNOB ASSEMBLY 1
3 10-0752005-71-00 VOLUME BEZEL 1
4 10-0752007-01-00 VIDEO COVER 1
5 10-0752011-00-00 LED LENS 1
6 10-0752012-01-00 RACKER BUTTON 2
7 10-0752015-01-02 LED BEZEL 1
8 10-0752017-01-00 PLASTIC FOOT 4
9 10-0752022-01-00 POWER BUTTON 1
10 10-0752025-01-00 RACKER BEZEL 2
11 10-0752032-01-00 INPUT BUTTON 4
12 10-0752032-01-00 DUO BUTTONS 2
13 10-0752045-01-00 POWER BUTTON BEZEL 1
14 10-0752055-01-00 DUO BEZEL 2
15 10-0752065-01-00 VIDEO HOUSING 1
16 10-0752075-00-00 DISPLAY BRACKET 1
17 10-0762035-71-00 INPUT BUTTON LOZENGE 1
18 11-0762005-80-00 HEX SPACER AF5.5 H8+6 10
19 11-0570075-80-01 L BRACKET 2
21 11-0752065-80-00 PHONE BRACKET 1
22 11-0762055-80-01 HEATSINK MOUNTING BRACKET 1
20 11-0762048-80-01 HEATSINK- RECTIFER 1
23 11-0762000-95-11 FASCIA 1
24*AH 11-0762003-85-12 TOP COVER 1
24*C 11-0762013-85-12 TOP COVER 1
25 11-0762004-80-02 BOTTOM CHASSIS 1
26*AH 11-0762006-94-12 REAR PANEL (AH) 1
26*C 11-0762016-94-12 REAR PANEL (C) 1
27 11-0762068-80-02 EXTRUDED HTSK LEFT 1
28 11-0762078-80-02 EXTRUDED HTSK RIGHT 1
29 11-0762025-80-01 SUBFASCIA 1
30 11-0762028-95-00 SIDE CAP L 1
31 11-0762038-95-00 SIDE CAP R 1
32 11-2100135-80-00 CLIP THERMAL SWITCH 1
33 12-0762001-70-00 FIBRE GASKET INSULATOR 1
34 14-0300803-54-00 TAPTITE SCREW 3 X 8 B/H BLK PLT 63
35 13-0260600-02-00 SELF TAP SCREW 2.6 X 6 P/H NI PLT 9
36 13-0260803-02-00 SELF TAP SCREW 2.6 X 8 B/H NI PLT 16
37 14-0300600-02-00 MACHINE SCREW M3 X 6 P/H NI PLT 19
38 14-0300600-04-00 MACHINE SCREW M3 X 6 P/H BLK 4
39 14-0300600-52-00 SELF TAP SCREW 3 X 6 P/H NI-PLT 28
40 14-0300800-53-00 SELF TAP SCREW 3 X 8 B/B ZINC PLT 39
41 14-0300804-54-00 TAPTITE SCREW M3 X 8 K/H BLK PLT 5
42 14-0301000-54-00 TAPTITE SCREW 3 X 10 P/H BLK 5
43 14-0301000-02-00 MACHINE SCREW M3 X 10 PAN HEAD NI PLT 25
44 14-0400802-04-00 MACHINE SCREW M4 X 8 WASHER HEAD BLK 6
45 14-0400803-54-00 TAPTITE SCREW 4 X 8 B/H BLK 4
46 14-0401002-04-00 MACHINE SCREW M4 X 10 WASHER HEAD BLK 1
47 15-0900220-11-30 NUT ZINC PLATED M9.0 X 2.2mm 1
48 16-0350080-04-35 STEEL WASHER I/D 3.5 X O/D 8.0 0.4mm ZINC PLT 6
49 17-0500960-00-01 PCB SUPPORTER H 9.6mm PCB HOLE 4mm 3
