Item Part No. Description Qty.
NOTE: THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR RISK OF FIRE AND
ELECTRICAL SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
<*AH > : USA, CANADIAN MODEL ONLY.
<*C > : EUROPEAN MODEL ONLY.
49 14-0301000-54-00 TAPTITE SCREW 3 X 10 P/H TYPE B BLK 5
50 14-0400802-04-00 MACHINE SCREW M4 X 8 WASHER 6
HEAD BLK
51 14-0400803-52-00 TAPTITE SCREW 4 X 8 B/H NI TYPE-B 6
52 14-0400803-54-00 TAPTITE SCREW 4 X 8 B/H BLK TYPE-B 4
53 14-0401002-04-00 MACHINE SCREW M4 X 10 WASHER 1
HEAD BLK
54 14-0801005-03-02 HEX.BOLT M8 LENGTH=100mm ZN PLATED 1
55 15-0300240-05-20 NUT M3 X 2.4mm 16
56 15-0807600-05-30 HEX NUT M8 X 6.5 THK 1
57 15-0900220-11-30 NUT ZINC PLATED M9.0 X 2.2mm 11p 1
58 16-0320560-09-20 SPRING WASHER I/D 3.2 X O/D 5.6 44
0.9mm THK
59 16-0350080-04-35 STEEL WASHER I/D 3.5 X O/D 8.0 0.4mm 22
ZINC PLT
60 16-0850160-10-30 METAL WASHER ID8.5 X OD16 X 1.0mm 1
NI PLT
61 16-0851500-12-30 SPRING WASHER I/D 8.5 X O/D 12.5 X 1.9THK 1
62 17-0500960-00-01 PCB SUPPORTER H=9.6mm PCB HOLE 4mm 3
63 17-1402603-30-22 RUBBER FOOT I/D14 X O/D26 X 3 PORON 4
HH-48C
64
25-0090056-00-21 XFORMER PW TOROIDAL 120V/240V 1
TI-0130203 ISS6
65*AH 29-4000003-00-38 AM/FM TUNER MODULE KST-MB114MA1-22 1
65*C 29-4000002-00-38 AM/FM TUNER MODULE KST-MB114MA1-23
66 34-0061030-00-67 JUMPER PLUG PITCH 14mm 6
67
34-0101000-00-67 AC SOCKET IEC 15A/250V 1
68*AH
34-0101001-00-70 AC OUTLET US POLARIZED 3512-MITIBKUC 1
68*C
34-0100002-00-78 AC OUTLET EURO CEE 7 2.5A/250V
A302D0060P
69 37-2011230-00-63 FAN DC 12V 0.09A 3000RPM W/450mm 2
CONNECTOR
70 37-2011230-01-63 FAN DC 12V 0.09A 3000RPM W/350mm 2
CONNECTOR
71 39-0000008-00-63 FAN GUARD 60mm DFG-60 4
