S-44
03-M Series, WSM
DIESEL ENGINE
Bushing Replacing Tools
Application: Use to press out and to press fit the bushing.
1. For small end bushing
2. For idle gear bushing
W1025500
Flywheel Stopper
Application: Use to loosen and tighten the flywheel screw.
W10259480
A 162 mm (6.38 in.)
B 35 mm (1.38 in.)
C 27 mm (1.06 in.)
D 35 mm dia. (1.38 in. dia.)
E 27.90 to 27.95 mm dia. (1.098 to 1.100 in. dia.)
F 25.00 to 25.01 mm dia. (0.984 to 0.985 in. dia.)
A 175 mm (6.89 in.)
B 40 mm (1.57 in.)
C 38 mm (1.50 in.)
D 45 mm dia. (1.77 in. dia.)
E 41.90 to 41.95 mm dia. (1.650 to 1.652 in. dia.)
F 37.95 to 37.97 mm dia. (1.494 to 1.495 in. dia.)
A 200 mm (7.87 in.)
B 30 mm (1.18 in.)
C 20 mm (0.79 in.)
D 15 mm (0.59 in.)
E 8 mm (0.31 in.)
F 10 mm dia. (0.39 in. dia.)
KiSC issued 08, 2012 A
