NAPCO StarLink SLE User Manual

StarLink
™
SLE Commercial Series Alarm Communicators -- Installation Instructions 9
Wiring Diagram for PRIMARY Reporting Configuration
GEM-P400 / GEM-P800 / Express XP-400 / Express XP-600 Control Panels
(Use when telephone line is NOT available)
CONTROL PANEL PC BOARD
6 7 8
17 16 15 14 13 12 11
9
10 2
3 4 5
1
19 18
(CONTROL PANEL HOUSING)
16VAC
*Refer to section "SUPPLYING POWER".
(–) (+)
AUX POWER
(RING)
(TIP)
6 7 8 15 14 13 12 11 9 10 2* 3 4 5 1*
+12V
(–)
PGM1 PGM2 PGM3 IN1 IN2 GND IN3 RING TIP
17 16
RTS
(R)
PANEL
TX (B)
PANEL
RX (G)
CTS
Y
StarLink Radio Terminals
PANEL
RING (+)
PANEL
TIP (–)
(–) (+)
(STARLINK RADIO HOUSING)
16VAC
Transformer
All connections are power limited except AC
Mains, Telco and battery terminals.
Terminals 14-17: No connections permitted.
ZONE (+)
DEDICATED TO
(PROGRAMMED FOR)
GPRS SUPERVISION
