11
W415-1401 / C / 03.18.15
EN
3.2 TYPICAL VENT INSTALLATION
16" (406MM)
MINIMUM
40 FT (12M)
MAXIMUM
3 FT (1M)
MINIMUM
34 1/16"
(865MM)
TOP VENT
8" (203MM)
MINIMUM
34 1/16"
(865MM)
42 1/16" (1068MM)
MINIMUM PLUS
RISE*
24" (610MM)
MAXIMUM
