3
W415-1401 / C / 03.18.15
EN
1.0 INSTALLATION OVERVIEW
See the section “MINIMUM
ENCLOSURE CLEARANCES”
for drywall (or other combus-
tible material).
See the section “MINIMUM
MANTEL CLEARANCES”.
See the section
“NON-COMBUSTIBLE
FINISHING”.
Side
Wall
See the section
“FRAMING”.
See the section
“VENTING” and
“INSTALLATION”.
See the section
“RATING PLATE
INFORMATION”.
SAFETY BARRIER
B36 ILLUSTRATED
Batteries must be disposed of according to the local laws and regulations. Some batteries may be recycled,
and may be accepted for disposal at your local recycling center. Check with your municipality for recycling
instructions.
17.0 GX36 MILLIVOLT VALVE TRAIN ASSEMBLY 67
18.0 GX36 ELECTRONIC VALVE TRAIN ASSEMBLY 68
19.0 GX36 ACCESSORIES 69
20.0 TROUBLESHOOTING (ELECTRONIC) 71
21.0 TROUBLESHOOTING (MILLIVOLT) 74
22.0 WARRANTY 77
23.0 SERVICE HISTORY 78
24.0 NOTES 79
