40
W415-0661 / 12.07.07
72* W175-0001 4" COUPLER
73* W175-0013 7" COUPLER
74* W615-0044 FIRESTOP SPACER - FLEXIBLE VENTING
75* W500-0103 TERMINAL EXTENSION PLATE
76 GD-301 HEAT GUARD
77* W010-0370 WALL SUPPORT ASSEMBLY
78* W175-0053 DURA-VENT ZERO CLEARANCE ADAPTOR
79 VS47KT VENT SLEEVE
80 W170-0063 VENT PIPE COLLAR
81 W585-0072 VENT PIPE SHIELD
82* W175-0159 CONVERSION KIT -
NG TO LP
83* W175-0164 CONVERSION KIT - LP TO NG
84* GD831KT DECORATIVE BRICK PANELS - SANDSTONE
85* CDV202-PB DOOR TRIM KIT
86* GD-565-1KT SAFETY SCREEN
87* S36WN WAVE SURROUND - BROWN
87* S36WP WAVE SURROUND - PEWTER
87* S36CCN CONCAVE SURROUND - BROWN
87* S36CCP CONCAVE SURROUND - PEWTER
87* S36CVN CONVEX SURROUND - BROWN
87* S36CVP CONVEX SURROUND - PEWTER
88* CFT36W UPPER TRIM FOR WAVE SURROUND
88* CFT36CC UPPER TRIM FOR CONCAVE SURROUND
88* CFT36CV UPPER TRIM FOR CONVEX SURROUND
Contact your dealer for questions concerning prices and avail-
ability of replacement parts. Normally all parts can be ordered
through your Napoleon® dealer or distributor.
When ordering replacement parts always give the following
information:
1. M
ODEL & SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
6. T
OP OR REAR VENT
COMMON REPLACEMENTS
COMMON COMPONENTS:
COMMON ACCESSORIES:
BGD36CF(G) FLEXIBLE VENT KITS:
BGD36CF(G) TERMINAL KITS:
BGD36CF(G) ROOF TERMINAL KITS:
BGD36CF(G) COMPONENTS:
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION,
CONTACT YOUR NAPOLEON® DEALER.
# PART NO. DESCRIPTION
1 W357-0001 PIEZO IGNITER
2 W680-0004 THERMOPILE
3 W680-0005 THERMOCOUPLE**
4 W010-0800 PROPANE GAS PILOT ASSEMBLY
4 W010-0801 NATURAL GAS PILOT ASSEMBLY
5 W455-0069 NATURAL GAS PILOT INJECTOR
5 W455-0067 PROPANE GAS PILOT INJECTOR
6 W725-0025 NATURAL GAS VALVE
6 W725-0026 PROPANE GAS VALVE
7* W385-0334 NAPOLEON® LOGO
8* W750-0112 20FT OF WIRE
9* W361-0016 GLOWING EMBERS
10* W550-0001 CHARCOAL EMBERS
** WARNING: THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTE-
GRAL SAFETY COMPONENT. REPLACE ONLY WITH A FAST ACTING
THERMOCOUPLE SUPPLIED BY WOLF STEEL LTD.
29* W225-0058 BLACK DOOR FRAME
30 W455-0048 #47 NATURAL GAS ORIFICE
30 W455-0047 #56 PROPANE GAS ORIFICE
31* W010-0370 WALL SUPPORT ASSEMBLY
32 W010-0539 FLUE PIPE ASSEMBLY c/w GASKET
33* W010-0538 FLUE CAP c/w GASKET
34 W010-0764 PAN BURNER
35 GL-639 LOG SET
36 W135-0183 BACK LOG (#1)
37 W135-0184 LEFT MIDDLE LOG (#2)
38 W135-0185 RIGHT MIDDLE LOG (#3)
39 W135-0186 LEFT CROSSOVER LOG (#4)
40 W135-0187 MIDDLE CROSSOVER LOG (#5)
41 W135-0188 RIGHT
CROSSOVER LOG (#6)
42 W010-0454 GLASS c/w GASKET
43 W010-0516 BLACK DOOR C/W GLASS
44 W010-1774 FIRESTOP SPACER
GD220 (5 FT)
57* W010-0397 4" FLEXIBLE VENT PIPE - (5
FT) C/W SPACERS
58* W410-0017 7" FLEXIBLE VENT PIPE - (5 FT)
GD330 (10 FT)
59* W410-0018 7" FLEXIBLE VENT PIPE - (10
FT)
60* W010-0300 4" FLEXIBLE VENT PIPE - (10 FT) C/W SPACERS
61* W010-0370 WALL SUPPORT ASSEMBLY
62 PERISCOPE - GD201
63 WALL TERMINAL KIT - GD222
64* 1/12 TO 7/12 PITCH - GD110
65* 8/12 TO 12/12 PITCH - GD111
66* FLAT ROOF - GD112
67* W490-0073 4/7 INNER/OUTER SLEEVE
68 W670-0006 4/7 TERMINAL
69 W170-0063 STORM COLLAR
70 W010-0453 ROOF SUPPORT
71 W263-0054 / ROOF FLASHING
W263-0055 /
W263-0056
11* W573-0007 10.3OZ TUBE HIGH TEMP SEALANT
12* W690-0001 MILLIVOLT THERMOSTAT
13* W690-0010B REMOTE CONTROL - Advantage
14* W660-0011B REMOTE CONTROL - ADVANTAGE PLUS
15* GD65 FAN KIT
16 GZ550-1KT BLOWER KIT
17* B440-KT BLOWER
18* W500-0033 VARIABLE SPEED SWITCH WALL MOUNTING PLATE
19* W690-0005 THERMOSTAT, 110 VOLT for use with ga-566
20* W660-0026 PROGRAMMABLE TIMER
21 GA-566 HOT AIR KIT
22 GA-72 HOT AIR EXHAUST KIT
23 GA-70 EXTENSION KIT 5
FT
24* ANI-K ANDIRONS - BLACK
25* ANI-G ANDIRONS - GOLD PLATED
26* 270 PAINT, BLACK - 13OZ
27* W361-0014 VERMICULITE
28* GD36
THERMOSTATIC SENSOR CONTROL KIT
FOR USE WITH GD65 ONLY
BGD36CF(G) ACCESSORIES:
BGD36CF(G) REPLACEMENTS
BGD36CFG COMPONENTS:
45 W100-0102 BURNER TUBE
46* W300-0102 CLEAR GLASS EMBERS
47* W010-1835 GLASS EMBER TRAY
48* W387-0004 HIGH TEMPERATURE LIGHT ASSEMBLY
49* W387-0006 HALOGEN BULB 10W T320
50* W725-0032 DEXEN VALVE EI NATURAL GAS
51* W725-0049 DEXEN VALVE 3V PROPANE
52 W455-0049 PILOT INJECTOR - LP
53 W455-0071 PILOT INJECTOR - NG
54 W720-0092 PILOT TUBE
55 W100-0069 PILOT ASSEMBLY - NG
56 W100-0093 PILOT ASSEMBLY - LP
