38
W415-0773 / E / 03.13.12
Combustion protrusions such as mantels and shelves may occur at or after a minimum distance of 2" away
from the side of the appliance. Thereafter, the depth of any protrusions must be equal to or less than the
distance from the side of the appliance up to a depth of 6", after which no greater clearance than 6" is required.
This can be considered a side wall with no length boundary.
6.2.1 MINIMUM FRAMING DIMENSIONS
36
1
/2”
35
3
/4”
3”
14
1
/2”
48 3/8”
(TOP EXIT)
39”
(REAR EXIT)
ENCLOSURE
TOP
FINISHING
MATERIAL
5
1
/2”
GAS
INLET
LOCATION
1
1
/2”
MAX
14”
MINIMUM
3
1
/2”
MAX
TOP EXIT INSTALLATION
SHOWN
36
1
/2"
14
1
/2"
14
1
/2"
INSIDE
CHASE
36
1
/2"
OUTSIDE
CHASE
4"
2"
SIDE
WALL
2"
4"
6"
PROTRUSION
36
3
/4"
36
1
/2"
52"
FOR TOP EXIT APPLICATIONS: DO NOT BUILD INTO THIS AREA. IT MUST BE LEFT CLEAR TO
PROVIDE ADEQUATE CLEARANCE FOR THE VENT. IN THIS 14" WIDE AREA CENTRED ALONG THE
FRONT OF THE APPLIANCE, NO COMBUSTIBLES ARE ALLOWED.
!
WARNING
* BGD36 HORIZONTAL VENT SECTIONS: A minimum of 1" at the bottom and sides and 2" at the top of the
vent pipe on all horizontal runs to combustibles is required. Use fi restop spacer W010-1774 (supplied).
* BGD36 VERTICAL VENT SECTIONS: A minimum of 1" all around the vent pipe on all vertical runs to
combustibles is required except for clearances in appliance enclosures. See "MINIMUM ENCLOSURE
CLEARANCES" section. Use fi restop spacer W500-0096 (not supplied).
