54
W415-0773 / E / 03.13.12
COMMON COMPONENTS
REF NO. PART NO. DESCRIPTION
1* W225-0058 BLACK DOOR FRAME
2 W357-0001 PIEZO IGNITER
3 W680-0004 THERMOPILE
4 W680-0005 THERMOCOUPLE **
5 W010-0800 PROPANE GAS PILOT ASSEMBLY
5 W010-0801 NATURAL GAS PILOT ASSEMBLY
6 W455-0069 NATURAL GAS PILOT INJECTOR
6 W455-0068 PROPANE GAS PILOT INJECTOR
7 W725-0025 NATURAL GAS VALVE
7 W725-0026 PROPANE GAS VALVE
8* W385-0334 NAPOLEON LOGO
9* W750-0112 20FT OF WIRE
10* W010-0538 FLUE CAP C/W GASKET
11 W010-0539 FLUE PIPE ASSEMBLY C/W GASKET
12 W010-0764 PAN BURNER
13 GL-667 LOG SET
14* W361-0016 GLOWING EMBERS
15* W550-0001 CHARCOAL EMBERS
16 W135-0378 REAR LOG
17 W135-0381 LEFT LOG
18 W135-0382 FRONT RIGHT LOG
19 W135-0380 LEFT CROSSOVER LOG
20 W135-0383 CHARCOAL STRIP
21 W135-0379 RIGHT CROSSOVER LOG
22 W010-0454 GLASS C/W GASKET
23 W010-0516 BLACK DOOR C/W GLASS
24* W290-0115 GASKET, VALVE TRAIN
12.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
• Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION, CONTACT YOUR
AUTHORIZED DEALER.
41.2
FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS MANUAL OR FAILURE TO USE
ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY
DAMAGE OR PERSONAL INJURY.
** THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTEGRAL SAFETY COMPONENT. REPLACE ONLY WITH
A FAST ACTING THERMOCOUPLE SUPPLIED BY WOLF STEEL LTD.
!
WARNING
