W415-2753 / A / 07.20.20
EN
2
table of contents
The information throughout this manual is believed to be correct at the time of printing. Wolf Steel
Ltd. reserves the right to change or modify any information within this manual at any time without
notice. Changes, other than editorial, are denoted by a vertical line in the margin.
note:
!
WARNING:
This product can expose you to chemicals including chromium, which are
known to the State of California to cause cancer, and chemicals including toluene, which are
known to the State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
1.0 general information 3
2.0 installation planning 4
2.1 installation option 1 - open enclosure (enclosure stops short of the ceiling) 5
2.2 installation option 2 - front opening 5
2.3 installation option 3 - rear opening 6
2.4 installation option 4 - open enclosure with hard combustible valance 7
2.5 installation option 5 - side openings 8
3.0 appliance overview 9
4.0 Dynamic Heat Control™ installation 10
4.1 high limit switch installation 13
5.0 minimum framing dimensions 15
6.0 minimum clearance to combustible enclosures 16
7.0 rough framing - before appliance installation 17
8.0 finish framing - after appliance installation 18
9.0 finishing 20
9.1 enclosure design 21
9.2 optional trim fi nishing 22
10.0 minimum combustible mantel clearances 23
11.0 maximum protrusion 24
12.0 Dynamic Heat Control™ installation checklist 25
