Napoleon Dynamic Heat Control - Maximum Finishing Protrusion

W415-2753 / A / 07.20.20
EN
24
fi nish framing - after appliance installation
• Finishing material tight to the frame around the fi nshing fl ange must not project more than 4” (38mm) from the
face of the safety barrier (above the door and sides only).
!
WARNING
11.0 maximum protrusion
4" (10cm)
Non-Combustible
Maximum
protrusion
(must not encroach
on finishing flange)
Barrier
Finishing
Flange (All
Around
Opening)
SIDE VIEW
4"
10cm
Max
