fi nish framing - after appliance installation
9.0 fi nishing
With Dynamic Heat Control™, you can fi nish the appliance with any com-
bustible materials. Air outlet opening must be located out of reach of the
user. Air outlet pening must not be restricted by furnishings or decor.
Recessed installation with Dynamic Heat Control™
Dynamic Heat
Control™ front
air outlet opening
Dynamic Heat
Control™ air
outlet opening
Dynamic Heat
Control™ side outlet
option (2 openings required)
note:
Recessed volume must be added
to the overal size of enclosure.
Dynamic Heat
Control™ side outlet option
(2 openings required)
