7.0 REPLACEMENT PARTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
• Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
COMPONENTS
REF NO. PART NO. DESCRIPTION
1 W660-0107 REMOTE CONTROL TRANSMITTER
2* W660-0108 REMOTE RECEIVER
3
W062-0040 BLOWER C/W HEATER
4 W387-0014 LAMP
5 W190-0038 CONTROL
6 W300-0141 FRONT GLASS
7* W435-0046 FAN MOTOR
8* W435-0047 DRUM MOTOR
9 W010-2433 DRUM
10* W550-0010 ROCK MEDIA
3
5
1
POWER
FUNCTION
FLAME
4
9
6
