9
W415-0931 / A / 11.04.10
4.0 FINISHING
4.1 MEDIA INSTALLATION
It is recommended that two people install this glass front onto the appliance,
Wear safety glasses and gloves when handling glass.
A. Line up the brackets on the back of the glass with the 4 shoulder
screws on the side of the appliance body.
B. Hang the glass front.
!
WARNING
POWER SUPPLY SERVICE MUST BE COMPLETED PRIOR TO FINISHING TO AVOID
RECONSTRUCTION.
HEAT VENTS AND AIR OPENINGS CANNOT BE COVERED IN ANY CIRCUMSTANCES.
4.2 GLASS FRONT INSTALLATION
A. CLEANING THE MEDIA: The media may have a fi ne white dust that needs to be cleaned prior to
installation. Clean the media with mild dish soap, drain, rinse thoroughly and dry before placing into
the tray.
B. Carefully place media into the bottom tray on the front of the appliance as illustrated.
Note: It is not necessary to use all the media supplied.
Shoulder
Screw
