W415-0931 / A / 11.04.10
4
1.1 DIMENSIONS
1.2 LISTING APPROVALS
This appliance has been tested in accordance with the CSA and UL Standards for fi xed and location-dedicated
electric room appliances in the United States and Canada. If you need assistance during installation, please
contact your local dealer.
NOTE: This appliance must be electrically wired and
grounded in accordance with local codes. In the absence
of local codes, us the current CSA C22.1 Canadian
Electrical Code in Canada or the ANSI/NFPA 70 National
Electrical Code in the United States.
Model Number EFL48
Description Wall-Mount Appliance
Voltage 120V AC / 60HZ
Watts MAX 1500W
Amps 15 AMP Grounded Circuit
Appliance Width 48.0"
Appliance Height 21.75"
Appliance Depth 6.5"
Gross Weight 56 lbs
Top View
Side View
21.75”
6.5”
48.0”
22.0”
Front View
38.25”
FAN
HEAT1
HEAT2
FLAME
FUNCTION
POWER
