Napoleon GSS42CFN - 1.0 INSTALLATION OVERVIEW; 3.0 INSTALLATION; 4.0 FRAMING; 5.0 FINISHING

W415-2164 / A / 07.21.16
2
EN
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 2
2.0 INTRODUCTION 3
2.1 DIMENSIONS 4
2.2 GENERAL INSTRUCTIONS 4
2.3 GENERAL INFORMATION 5
2.4 RATING PLATE INFORMATION 5
3.0 INSTALLATION 6
3.1 GAS INSTALLATION 6
3.2 GAS INLET LOCATIONS 7
3.3 OPTIONAL WALL SWITCH INSTALLATION 7
3.4 COMBUSTION AND VENTILATION AIR 8
4.0 FRAMING 8
4.1 CLEARANCE TO COMBUSTIBLES 8
4.2 MINIMUM ENCLOSURE CLEARANCES 10
4.3 MINIMUM MANTEL CLEARANCES 11
4.4 NAILING TAB 11
5.0 FINISHING 12
5.1 LOG PLACEMENT 12
5.2 GLOWING EMBERS (OPTIONAL) 13
5.3 CHARCOAL LUMPS/LAVA ROCK 13
5.4 LOGO PLACEMENT 14
6.0 OPTIONAL REMOTE INSTALLATION 14
7.0 OPERATION 15
8.0 ADJUSTMENT 16
8.1 VENTURI ADJUSTMENT 16
8.2 FLAME CHARACTERISTICS 16
9.0 MAINTENANCE 17
10.0 REPLACEMENTS 18
10.1 OVERVIEW AND VALVE TRAIN ASSEMBLY 19
11.0 ACCESSORIES 20
12.0 TROUBLESHOOTING 21
13.0 WARRANTY 23
1.0 INSTALLATION OVERVIEW
Batteries must be disposed of according to the local laws and regulations. Some batteries may be
recycled, and may be accepted for disposal at your local recycling center. Check with your municipality
for recycling instructions.
Les piles doivent être mises au rebut conformément aux lois et à la réglementation locales. Certaines
piles peuvent être recyclées et acceptées dans votre centre de recyclage local. Renseignez-vous auprès
de votre municipalité au sujet des directives de recyclage.
NOTE: The camera icon indicates video tutorials are available as additional reference, visit
http://mynapoleon.napoleonproducts.com/download/index/44/1
Refer to “GRATE
ASSEMBLY” section.
Refer to “RATING
PLATE INFORMATION”
section.
