• keep away from suspended loads
• always wear accident prevention equipment
• be careful not to damage electrical cables
Do not handle the product using electrical cables as lifting gear.
WARNING
Failure to follow the instructions may result in damage to the product, the system in which it is
installed and, in the worst cases, damage to property or persons with even fatal consequences.
4.4. Storage
The product must be stored in its packaging in a dry place, without sudden changes in humidity and temperature
and protected from mechanical (weights, vibrations), thermal and chemical agents.
The temperature of the storage environment must be between -20°C (-4°F) and 70°C (+158°F) with a maximum
relative humidity of 85% (non-condensing).
If the product remains in stock for more than 24 months from the manufacturing date shown on the packaging, it is
necessary to check the mechanical integrity of its parts and supply power to it at least once every 12 months.
If the product is put back into storage after it has been used, it is advisable to contact the manufacturer for further
information on storage.
TIP
For more information contact the dealer or technical support at service@nastec.eu or by opening a
support ticket on the portal service.nastec.eu
5. Technical features
5.1. Technical Data
Electrical specifications by model:
Model V +/- 10% [VAC] Max I [A] Typical motor P2 [kW]
50 Hz
Typical motor P2 [kW]
60 Hz + S.F.
PILOT 112 1x230V 1 x 230 12 1,5 1,1
PILOT 118 1x230V 1 x 230 18 2,2 1,5
PILOT 312 3x230V 3 x 230 12 2,2 2,2
PILOT 325 3x230V 3 x 230 25 4 3,7
PILOT 330 3x230V 3 x 230 30 5,5 5,5
PILOT 312 3x400V 3 x 400 12 4 -
PILOT 325 3x400V 3 x 400 25 9,2 -
PILOT 330 3x400V 3 x 400 30 11 -
PILOT 312 3x460V 3 x 460 12 - 3,7
PILOT 325 3x460V 3 x 460 25 - 7,5
PILOT 330 3x460V 3 x 460 30 - 11
General electrical specifications:
Power supply frequency 50 - 60 Hz (+/- 2%)
Voltage unbalance between the power supply phases +/- 2%
EMC compliance EN61800-3 C2
Environmental specifications:
Maximum workplace temperature at nominal load 40°C (104 °F)
Power derating beyond maximum temperature -2.5% every °C (-1.4% every °F)
Maximum altitude at nominal load 1000 m (3280 ft)
Power derating beyond maximum altitude - 1% every 100 m (328 ft)
PILOT
10
