WARNING
Use shielded cable for control cables.
WARNING
Always use cables with appropriate cable lugs, which may be supplied with the product.
7.3. Protection devices
DANGER
It is recommended to install the appropriate protection devices upstream of the device, such as a
circuit breakers, fuses and a residual current device (RCD).
Fuses and switches.
The control device can protect the motor from overloads by digitally controlling the absorbed current against the set
rated current.
Instead, it is necessary to install overcurrent and short-circuit protection devices, such as fuses and circuit break-
ers, upstream of the device. These trigger in the event of failure of a component inside the device.
Supply voltage Model Recommended fuse
gC
Recommended circuit breaker
ABB MCB S200
1 x 230 VAC PILOT 112 1x230V 16 S201-C16
1 x 230 VAC PILOT 118 1x230V 25 S201-C25
3 x 230 VAC PILOT 312 3x230V 16 S203-C16
3 x 230 VAC PILOT 325 3x230V 32 S203-C32
3 x 230 VAC PILOT 330 3x230V 32 S203-C32
3 x 400 VAC PILOT 312 3x400V 16 S203-C16
3 x 400 VAC PILOT 325 3x400V 32 S203-C32
3 x 400 VAC PILOT 330 3x400V 32 S203-C32
3 x 460 VAC PILOT 312 3x460V 16 S203-C16
3 x 460 VAC PILOT 325 3x460V 32 S203-C32
3 x 460 VAC PILOT 330 3x460V 32 S203-C32
Residual Current Devices (RCD)
Use type AC or A RCD devices.
7.4. Electrical connections
PILOT
