Parameter Description
P.F = X.XX The P.F. parameter represents the measured power factor (cosØ).
STATUS: NORMAL In the absence of alarms, the STATUS is NORMAL.
Otherwise, the alarm message flashes.
Press th ENTER key to access the Diagnostics menu.
To return to the initial display, simply press the ENTER key.
MENU'
ENT to access
Press the ENTER key to access the menu display.
9.2.2. Diagnostics
Parameter Description
Motor starts
XXXXX h : XX m
Number of restarts performed by the motor
Motor hours
XXXXX h : XX m
Motor life hours
ALL. XXXXXXXXXXXXX
XXXXXXX h : XX m
Alarm log in relation to motor hours
9.3. Menu
To access the Menu section, press the ENTER key on the MENU' / ENT to accessscreen. To exit the Menu section,
press the STOP button several times until you go back to the Home screen.
NOTE
Stop the motor before entering the Menu section.
The menu is password-protected (default 001).
The access password can be changed from the menu.
NOTE
When an incorrect password is entered to access the menu, the parameters can only be displayed
but not edited.
In case of loss of the password, contact the technical support service to obtain the universal pass-
word.
9.4. Parameters
Parameter Default Description
Amp. max Maximum current absorbed by the motor beyond which the device intervenes by stopping the pump.
It corresponds to the rated motor current increased by 10%.
Dry run PF Minimum power factor (or cosØ) below which the device intervenes by stopping the pump. The dry
running condition is characterized by a low power factor value. Contact the pump manufacturer for
more information.
Restarts delay 10 Time base that establishes the delay of attempts to restart the pump following a no-water alarm. With
each attempt, the delay time is doubled. The maximum number of attempts is 5.
Max restarts 5 Maximum number of restarts per minute beyond which the device intervenes by stopping the pump.
Digital input1 N.O. If N.O.(Normally Open) is selected, the device will continue to operate the motor if digital input 1 is
open. Conversely, it will stop the motor if digital input 1 is closed.
If N.C. (Normally Closed) is selected, the device will continue to operate the motor if digital input 1 is
closed. Conversely, it will stop the motor if digital input 1 is open.
Digital input2 N.O. If N.O.(Normally Open) is selected, the device will continue to operate the motor if digital input 2 is
open. Conversely, it will stop the motor if digital input 2 is closed.
If N.C. (Normally Closed) is selected, the device will continue to operate the motor if digital input 2 is
closed. Conversely, it will stop the motor if digital input 2 is open.
Change PASSWORD By pressing the ENTER key it is possible to change the password (default 001).
PILOT
22
